PET Bottled 10000BPH 3 in 1 Purified Water Filling Machine
It is a full-automatic multiple-function washing, filling and capping unit. Three parts connect with one line .It is used in washing, filling and sealing all kinds of drinks such as fruit juice, gas beverage, mineral water and pure water. The line has features of unique design, new style, complete functions, multi-purpose, convenient in operation, beautiful construction, high automation. It is the best filling equipment in China. It adopts corrosion-resistant stainless steel 304. It is sturdy, with good look and finish, cost efficient and trouble free.In the same time, the machine adopts PLC control system touch screen digital panel.
Main Parameter for PET Bottled 10000BPH 3 in 1 Purified Water Filling Machine
Mars Model | CGF14-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 | CGF40-40-12 |
Production Capacity(500mm)(b/h) | 3000-5000 | 5000-7000 | 7000-9000 | 10000-12000 | 12000-15000 |
Filling Precision | ≤±5mm(Liquid Level) | ||||
Polyester Bottle Standard(mm) | Diameter: D40-D80, Height: 130-280mm | Bottle Diameter D50-D100,Height:150-320mm | |||
Suitable Cap Shape | Plastic Screw Cap | ||||
Water Pressure of Washing Bottle(Mpa) | 0.18 | ||||
Water Consumption for Water Bottle(kg/h) | 800 | 1600 | 2500 | 3500 | 4500 |
Spraying Position | 5 | 5 | 6 | 12 | 5 |
Dripping Bottle Position | 3 | 3 | 3.5 | 7 | 8 |
Gas Source Pressure(Mpa) | Normal Pressure | ||||
Gas Consumption(m3/min) | 0.3 | 0.3 | 0.4 | 0.5 | 0.6 |
Total Power(kw) | 4.23 | 5.03 | 6.57 | 8.63 | 9.63 |
Total Weight | 2000 | 3500 | 5500 | 6000 | 8000 |
Dimension(L*W*H)(mm) | 2100*1500*2200 | 2450*1800*2200 | 2750*2180*2200 | 3500*2200*2250 | 3500*2200*2250 |
PET Bottled 10000BPH 3 in 1 Purified Water Filling Machine
