Purified Water Production Line
Product Introduction:
(1) This bottling machine is mainly used for washing, filling and capping PET bottle which can fill non- carbonated drinks such as mineral water, pure water, wine and so on.
(2) Bottle washing, filling and capping are achieved in one machine.
(3) The contact time is shorten between material and the outside. And improved the health conditions, production capacity and economic benefits.
(4) CGF series bottling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster and more laborsaving.
(5) The main machine adopts advanced PLC control technology. The key electric elements adopt Mitsubishi, Omron, Siemens, etc international famous products.
Main technological data for Purified Water Production Line :
Model |
CGF12126 |
CGF18186 |
CGF24248 |
CGF323210 |
CGF404012 |
CGF505012 |
CGF606015 |
CGF808020 |
Number of washing, filling and capping heads |
12-12-6 |
18-18-6 |
24-24-8 |
32-32-10 |
40-40-12 |
50-50-12 |
60-60-15 |
80-80-20 |
Production capacity(600ml) (B/H) |
2000-4000 |
5000-7000 |
8000-12000 |
12000-15000 |
16000-20000 |
20000-24000 |
25000-30000 |
35000-40000 |
suitable bottle specification(mm) |
φ=50-110 H=170 volume=330-2250ml |
|||||||
Washing pressure(kg/cm 2 ) |
2-3 |
|||||||
Motor power(kw) |
Main motor2.2kw |
Main motor2.2kw |
Main motor3kw |
Main motor5.5kw |
Main motor7.5kw |
Main motor11kw |
Main motor15kw |
Main motor 19kw |
Overall dimensions (mm) |
2400×1650×2500 |
2600×1920×2550 |
3100×2300×2800 |
3800×2800×2900 |
4600×2800×2900 |
5450×3300×2900 |
6500×4500×2900 |
76800×66400×2850 |
Weight (kg) |
2500 |
3500 |
4500 |
6500 |
8500 |
9800 |
12800 |
150 |
