Electric Pallet Stacker

Electric Pallet Stacker

Advantages:

SAFETY AND PRODUCTIVITY:

• Two pallets handled at one time.
• Side-way battery with roll-out system is very convenient to replace batteries. The battery upside cover makes you easy to fill the battery.
• Full free lift.
• Emergency reversing device.
• Built-in pressure relief valve protects the trucks from overloads.
• Emergency power disconnect.
• Low speed switch in the handle.
• Stepless speed control.

  STRUCTURAL:
• Low Center of Gravity ensures the stable operation.
• Spring-loaded castors improve lateral stability on uneven floors and enhance truck performance and service life.
• Heavy duty German masts.

  SERVICEABILITY:
• Low battery protection setting prolongs the battery use time.
• CANbus technology.
• Hall-effect throttle control eliminates wear components and requires no mechanical adjustment.

  Main specifications:

  Model		CDD10S	CDD15S
  Drive type		Electric
  Operation type		standing
  Load capacity/rated load	Q(Kg)	1000	1500
  Load centre distance	c(mm)	500	500
  Load distance,centre of drive axle to fork	x(mm)	844
  Fork height,lowered	h13(mm)	95
  Wheelbase	y(mm)	1420	1440
  Axle loading,laden front/rear	kg	918/942	1168/1352
  Axle loading,unladen front/rear	kg	639/221	755/265
  Tyres		polyurethane
  Tyre size,front	mm	φ250×80
  Tyre size rear	mm	φ80×70
  Additional wheels(dimensions)	mm	φ150×60
  Wheels,number front rear(x=driven wheels)		1x+2/4
  Tread,front	b10(mm)	626
  Tread,rear	b11(mm)	470
  Height,mast lowered	h1(mm)	2082/1852/2102/2252/2352
  Free lift	h2(mm)	1600/1300/1555/1705/1805
  Max. lift height	h3(mm)	1600/2500/3000/3300/3500
  Height,mast extended	h4(mm)	2082/3062/3562/2862/4062
  Initial lift	h5(mm)	120
  Height of tiller in drive position min./max	h14(mm)	1065/1350
  Overall length	l1(mm)	1910	1930
  Length to face of forks	l2(mm)	810	830
  Overall width	b1(mm)	780
  Fork dimensions	s/e/l(mm)	60/180/1100
  Width overall forks	b5(mm)	650
  Ground clearance,centre of wheelbase	m2(mm)	27
  Aisle width for pallets 1000x1200 crossways	Ast(mm)	2567	2587
  Aisle width for pallets 800x1200 lengthways	Ast(mm)	2502	2522
  Turning radius	Wa(mm)	1730	1750
  Travel speed,laden/unladen	Km/h	4/5
  Lift speed,laden/unladen	m/s	0.08/0.1
  Lowering speed,laden/unladen	m/s	0.15/0.12
  Max.gradeability,laden/unladen	%	6/10
  Service brake		Electromagnetic
  Drive motor rating S2 60 min	kW	0.75
  Lift motor rating at S3 15%	kW	2.2
  Battery voltage,nominal capacity K5	V/Ah	24/240
  Battery weight	kg	240
  Battery dimensions l/w/h	mm	650x249x500
  Sound level at the driver's ear acc.to DIN 12053	dB(A)	70
  Service weight(with battery)	kg	860/880/890/900/910	1020/1040/1050/1060/1070
