Automatic Shrink Wrapper Shrink Bundle Machine
Characteristic:
- Specially designed for the full automatic packaging production line of beer, beverage, pure water, fruit juice, dairy products, etc.
- With full automatic functions of bottle transfer and arrange, membrane packing, sealing and cut, shrinkage, cooling and shaping, etc.
- Using advanced constant temperature membrane theat binding technology in the world with clear and secure seal.
- The quick seal cooling structure guarantee that the seal has higher strength even if under high speed production condition.
- Adopt with PLC automatic program circulation control with stable and reliable performance.
- The original imported guide bar cylinder guarantee correct operation and durable.
- The inductive switch controls the membrane transfer system to reliably adjust and control the membrane transfer length with less loss.
- All the transfer system is controlled by frequency changing devices with stable and smooth transfer speed.
- Unique thermal passage with 2 sets of centrifugal thermal air circulation system that has an equal heat distribution with beautiful and secure shrinkage effect.
- 3 layers of heat insulation treatment with good insulting property, quick temperature rise and energy saving.
- The enhanced cooling shaping passage can quickly turn the packing membrane into high strength status that is conveniently stored and transported.
- It is easy to change the packaging combination and bottle type to integrate the multi-function into one machine.
Main Technical Parameter:
Model: SP-15
Packing speed: 13-15Packagers/Min
Suitable bottle material: glass bottle, pop-top can, PET bottle and material which can bear 200°C.
Suitable bottle specification: bottle diameter: Φ60-120Φmm
Bottle height: ≤340mm
Packing material: PE Hot shrink film
thickness: 0.03-0.10mm max. film width: 600mm
Packing method: two sides sealing while two sides open
Working pressure: ≥0.6Mpa(dry air),gas consumption: 25m3/H
Suitable voltage: 50Hz/380V, 3 phase
Power: 28Kw
Weight: 1300Kg
Conveyor height and bottle inlet direction, size: according to customer request
Equipment safety reach to standard requirement.
Main Parts Origin:
No. |
Parts name |
Model |
Qty |
Brand |
1 |
PLC |
XC3-32T-E |
1 |
MITSUBISHI |
2 |
Touch screen |
TP560-L |
1 |
MITSUBISHI |
3 |
Inverter |
3 phase, 0.75KW |
1 |
MITSUBISHI |
4 |
Contactor |
3TB40 |
4 |
SIEMENS |
5 |
Electric door lock |
3TB44 |
1 |
SIEMENS |
6 |
Thermo relay |
1.8A |
3 |
SIEMENS |
7 |
SSR |
SAP 4020D |
1 |
DONGQI,HONGKONG |
8 |
Temperature control instrument |
TE7-RB10 |
1 |
DONGQI,HONGKONG
|
9 |
Motor |
|
|
SIEMENSE BEIDE |
10 |
Pneumatic parts |
|
|
AIR TAC |
11 |
Intermediate relay |
HH52P 24VDC |
2 |
OMRON |
12 |
Proximity switch |
PR12-4DN |
3 |
AUTONICS |
13 |
Photo electricity switch |
BR100-DDT |
3 |
AUTONICS |
14 |
Magnetic switch |
CS1-F |
5 |
AIRTAC |
15 |
photoelectric cell |
ZT-1200N |
1 |
OPTEX FA |
16 |
Mirror photo electricity |
BM1M-MDT |
1 |
AUTONICS |
17 |
AIR SWITCH |
DZ47 C6 2P |
3 |
DELIXI |
18 |
Alarm light |
YT703 |
1 |
|
19 |
Switch power |
HS-350-24 |
1 |
TAIWAN |
Product show
