Bottle Film Shrink Packaging Machine
Introduction:
The shrink packing machine specially designed for packing production line of beer , beverage, pure water
fruit juice ,dairy products ,etc. with full automatic functions of bottle transfer and arrange,membrane packing ,sealing and cut ,shrinking cooling and shaping etc.
Advantages:
1)Shrink packing machine using advanced constant temperature membrane heat binding technology in the world with clear and secure seal .
2)The quick seal cooling structure guarantee that the seal has a higher strength even if under high speed production condition .
3)Adopt with PLC automatic program circulation control with stable and reliable performance .
4)The inductive switch control the membrane transfer system to reliably adjust and control the membrane transfer length with less loss.
5)All the transfer system is controlled by frequency changing devices With stable and smooth transfer speed Unique thermal passage with 2 sets of centrifugal thermal air circulation system that has an equal heat distribution with beautiful and secure shrinkage effect.
Features:
1) Frequency converter speed adjust,two segment convey device.
2) Bottle pushing, thermo sealing and cutting whole movement adopt to pneumatic fracture.
3)Proximity switch control film length
4) Touch screen, PLC system greatly increase facility movement reliability.
5) Three-wind recycle fan machine, ensure shrinkage tunnel inside even temperature.
6) Super big wind-volume cooling system, ensure quickly get into shape .
7) Anti-high temperature teflon convey belt, convey steadily, high-strength anti-abrasion.
8)Frequency limitless speed adjust convey belt frame.
9)Convey belt height can make according client requirement, adjust range:±100mm
10) Wing stainless steel heating system, endurance
11) Meet with product instant stop requirement product-bearing rack device ensure production line consistency.
Technical Parameters:
Dimension For the whole unit | L5050×W3300×H2100mm |
Thermal Shrinkage Passage Dimension | L1800×W600×H450mm |
Packing Speed | 10 bag |
| Shrinkage film thickenss | 0.03-0.15mm |
Thermo shrinkage tunnel max temperature | 160 - 260° adjust at will |
| Air pressure | 0.6-0.8mpa |
Working noise | ≤65db |
Product show
