Home > Manufacturing & Processing Machinery > Plastic Machinery > Blow Molding Machine > 100ml to 6L Bottle Making Machine
US$ 10,000 - 11,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PET
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Plastic Bottle Molding MachineUS$ 50,000 - 90,000MOQ: 1 Set -
PET Stretch Blow Molding MachineUS$ 45,000 - 50,000MOQ: 1 Set
-
Drinking Water Bottle Blowing MachineUS$ 14,000 - 15,000MOQ: 1 Set
-
Barrel Molding MachineUS$ 9,000 - 11,000MOQ: 1 Set
-
Automatic PET Bottle Blowing MachineUS$ 45,000 - 50,000MOQ: 1 Piece
Condition
New
Application
Bottle
Plastic Processed
PET
Blow Moulding Type
Stretch Blow Moulding
Automatic
Yes
Place of Origin
Jiangsu, China
Brand Name
Mars
Model Number
BM-S2
Voltage
380V
Power(W)
12Kw
Dimension(L*W*H)
1700*600*1700mm
Weight
1000Kg
Certification
CE
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Machine Features:
- Adopt the new type double bend arm and four pull rod-clamping structure (won the patent). Cross direction; middle mould board is move parallel; the distance between two mold bases is adjusted by the chain wheel. Thus, the clamping force is very strong.
- The machine frame is produced by the whole complete casting bottom, so that the machine is firm and running stable.
- Adopt the straight slide way, reduce the friction and lengthen the life of the machine.
- Double start working button, which is designed for avoiding the injury.
- Power saving design that can increase your profits.
- The single direction of pre-form placing and bottle picking, which increase the output.
- Segregate type air controlling system, which is designed for avoiding waste pollution.
- The stretching air cylinder is adjusted parallel from front to back, from left to right freely by regulator.
Machine Parameters:
GENERAL INFORMATION | BM-A2 |
Theoretical output | 1000pcs/hr for 3L & 450pcs/hr for 8L |
Heating capacity | 12kw |
Max. bottle volume | 3L(2cavities)&6L(1cavity) |
Blowing pressure | ≤3.5Mpa |
Motion pressure | ≤1.0Mpa |
Max. diameter × height | Φ180×H370mm |
Mould thickness | 160-260mm |
Weight | 1000kg |
Main machine dimension | 1700×600×1700mm |
Heater dimension | 2000×650×1450mm |
Product show
