Bottle PET Injection Molding Machine
Our machine have some advantages as following:
SPECIFICATIONS |
UNITS |
JWB50 |
Max container capacity |
L |
2 |
Number of die heads |
Set |
1,2,3,4 |
Out put ( dry cycle ) |
Pc/hour |
1500 |
Machine dimension (L*W*H) |
M |
2.8*1.7*2.5 |
Total weight |
Ton |
4.5 |
CLAMPING UNIT | ||
Clamping force |
KN |
56 |
Platen opening stroke |
mm |
200-500 |
Platen size |
mm |
330*370 |
Move mould stroke |
mm |
420 |
Mould thickness |
mm |
205 |
POWER | ||
Motor power of oil pump |
KW |
7.5/11 |
Max pressure |
Mpa |
10 |
Fan power for screw |
KW |
0.14*3 |
Air pressure |
Mpa |
0.6 |
Air consumption |
M3/min |
0.4 |
Average energy consumption |
KW |
17 |
EXTRDER UNIT | ||
Screw diameter |
mm |
50 |
Screw L/D ratio |
L/D |
24 |
Plasticizing capacity |
Kg/hour |
40 |
Number of heating zone |
Zone |
3 |
Extruder heating power |
KW |
10.8 |
Extruder driving power |
KW |
11 |
DIE HEAD | ||
Number of heating zone |
Zone |
2 |
Power of die heating |
KW |
4.2 |
Max die pin diameter |
mm |
75 |
Center distance of double die |
mm |
130 |
Company introduce:
1.Terms of payment: T/T 30% payable as deposit, the others shall be paid before shipment
2.Manufacturer equip:
1)Technology:who are specialized filed of designing plastic machines more 10 years ,assure the precision.
2) Two sets parallel lathe: make big accessories by ourselves.
3) Lathing, milling, planning, attrition, boring, drilling, cutting board, bending board, and jointing tools: meet all requirement.
4)Use the precision equipment and advanced casting machine, adopting advanced technology, 45#,38CrMoAlA, to manufacture the accessories. Steel structure is stable and it has long lifetime to keep the precision of parts.
3.Quality control:
We got theTUV quality certification several years ago. Recently, we got the CE quality certification. Good quality system makes our product quality at the high level.
1) Mould die head heating oil :which are supplied by special made manufacturer
2) There is accessories transfer case from manufacturing to installing for accessories to make all accessories no falling during the whole process.
3) All configurations are used international brand and national famous brand.
4) All single machines are running more than 80 hours before delivery the factory. After check by quality department, machines could be delivered.
5) our machine which can save energy is about 25-30% than other supplier
Product show
