Tubular UHT Sterilizing Machine

Tubular UHT Sterilizing Machine thumbnail-1
Tubular UHT Sterilizing Machine photo-1
US$ 66,000 - 69,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Mars
Contact Supplier Request Quote Chat Now
Zhangjiagang Mars Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Mars
Model Number UHT-2000
Processing Types Milk
Power(W) 6Kw
Weight 2160Kg
Dimension(L*W*H) 3.5*1.8*2.0m
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

UHT Sterilizing Machine



1.Product introduction

The sterilization process of tubular ultra-high temperature sterilizer not only can be suitable for common products, but also can satisfy special requirements of customers,for example:long term production of products with granules or medium and high viscosity. Such an cream,pure milk ducts(milk, fruit juice and cream )of high viscosity:products containing fiber and larger pulp granules, products of high acidity and products corrosive to the dead angle. The products can be sterilized at high temperature and ultra-high temperature of 120~140°C.

Main features:Hard to agglomerate,long working time;PLC control with simple and correct operation;touch screen display, which is direct and full; self-provided CIPcleaning system,easy cleaning;reliable materials with high pressure withstanding capacity;low maintenance cost. It can be customized to satisfy infividualized requirements of different customers.



2.Technology introduction

Technology  5°C→65°CHomogenization→95°C30S→140°C4S→25°C

Ice water 1,1(≤2°Cspare)   Cooling water 1,1(30°Cspare)



3.Technical parameters



model and specification

capacity

steam consumption

steam pressure

power

outline dimensions of integral type

outline dimensions of split type

weight

pipe diameter

t/h

kg/h

bar

kw

l*w*h

l*w*h

kg

material

steam

medium

UHT-1000

1

40

6.0

4.0

3.3*1.6*1.8



1960

25

DN25

25

UHT-1500

1.5

60

6.0

4.0

3.3*1.6*1.8



1960

25

DN25

25

UHT-2000

2

80

6.0

6.0

3.5*1.8*2.0



2160

38

DN25

38

UHT-3000

3

120

6.0

6.0

3.5*1.8*2.0



2420

38

DN32

38

UHT-4000

4

160

6.0

7.0

4.5*2.0*2.0

6.5*0.9*1.4

2570

38

DN32

38

UHT-5000

5

200

6.0

7.0

4.5*1.8*2.0

6.5*0.9*1.4

2940

51

DN40

51

UHT-6000

6

240

6.0

7.0

4.5*2.0*2.2

6.5*0.9*1.4

3300

51

DN40

51

UHT-8000

8

320

6.0

11.0

4.5*2.0*2.2

6.5*0.9*1.4

3700

51

DN50

51

UHT-10000

10

400

6.0

11.0

4.5*2.0*2.2

6.5*0.9*1.4

4200

51

DN50

51



Product show

Tubular UHT Sterilizing Machine

Tubular UHT Sterilizing Machine

Tubular UHT Sterilizing MachineTubular UHT Sterilizing Machine
