MAST-A High Efficiency large vacuum
autoclave Shinva Steam Sterilizer
Shinva Steam Sterilizer
MAST-A is a fast, compact and versatile sterilizer which is researched and
developed according to the latest requirements of medical institution and CSSD. It is
designed and manufactured combines high capacity with cost-efficiency, while offering
high operating reliability and easy maintenance.
The design of chamber accords with state GB1502011, GB8599-2008, and European
EN285 standard.
Product features
Superb chamber machining and welding process
The acid-proof stainless steel chamber and jacket are automatically robot-welded to
guarantee long time and trouble-free operation.
Nice chamber surface
Surface Smoothness, Ra≤0.5; No welding part or bolt in the chamber which
effectively protects the items to be sterilized. Steam baffle plates are surrounded by
silicon rubber protecting the chamber surface.
Reliable and durable chamber
Chamber is designed according to professional analytical method. High-emulation
software ANSYS is used for chamber simulation. Design service life: 10 years
(or 20000 times sterilization)
Reasonable sealing structure
Compact designed sealing groove, durable circular hollow silicon gasket, sealed by
compressed air.
Hanged door automatically
The door is driven by a motor automatically, stable and easy operation. Door
concave-convex tooth structure ensures its safety and durability.
Precise pressure detecting and control
Intelligent pressure transmitters, Wika (Germany), ensure steam pressure detecting
and control both in Chamber and jacket.
Unique vacuum noise-reduction system
LNS low-noise and water-saving vacuum system, effective reduced the noise during
running.
Humanized operation system
Colorful touch screen on loading-side, 6 indicating lamps on unloading sides, which
are concise, vivid and exactly showing sterilization running status and alarming
information.
Reasonable pipeline layout
All the pipes, valves and components are designed and installed in single side, which
is more convenience for repair and maintenance. The sterilizers can be installed
against the wall and also, two sterilizers can use the same maintenance space to save
installation space.
Scientific design parameters, wide scope of application
Item |
Chamber |
Jacket |
Design pressure MPa |
-0.1/0.3 |
0.3 |
Design temperature ℃ |
144 |
144 |
Working pressure MPa |
0.25 |
0.25 |
Max. Working temperature ℃ |
139 |
139 |
Safety valve open pressure |
0.28 |
0.28 |
7.0’’ SIEMENS color display touch screen
CPU226 SIEMENS PLC as central processor
Display information:
Jacket pressure P1 |
Chamber pressure P2 |
| Chamber temperature T2 |
| Door operation |
| Printer ON/OFF |
| Operator ID and password |
| Alarm display and record |
| Program selection |
| Cycle process and values in real time |
| System parameter setting |
Manual operation |
A variety of program
| Fabric 121℃ and 134℃ |
| Instrument 121℃ and 134℃ |
| Liquid 121℃ |
| Rubber 121℃ |
| Flash 134 ℃ |
| Gravity 121℃ |
| Automatic leak test |
| User-defined |
| Demo |
Humanistic indicating system
| Back door closing indicating lamp |
| Cycle running lamp |
| Cycle end indicating lamp |
| Breakdown indicating lamp |
| Power lamp |
sterilizer
sterilizer
sterilizer
sterilizer
