Steam element / Cold and hot cylinder
Hangzhou HUIHE mechanical equipment co., LTD., the production of steam heating cold and hot cylinder using scope is very broad. In the food, dairy products, chemical, pharmaceutical, beverage and other industries widely used, especially in the beverage, dairy production, often with cold and hot cylinder to heating of the material, cooling, neutralization, reaction, mixing, etc.
Steam boiler heating element characteristics
1, Quick open manhole
2, Various types of CIP cleaning device
3, Fly insect breathable cover health level
4, Adjustable triangle leg
5, Removable feeding tube
6, The thermometer (according to customer requirements)
7, The ladder (according to customer requirements)
8, Vertical agitator (according to the demand of customers paddle or frame).
9, Jacketed (according to the demand of customers miller board, hollow jacket or coil jacket)
10, Liquid level meter and level control (according to customer requirements)
Steam element / Cold and hot cylinder technical parameters
Volume |
300L |
400L |
500L |
600L |
800L |
1000L |
1500L |
2000L |
3000L |
Body diameter(mm) |
Φ800 |
Φ800 |
Φ900 |
Φ1000 |
Φ1000 |
Φ1000 |
Φ1200 |
Φ1300 |
Φ1600 |
Body height(mm) |
600 |
800 |
800 |
800 |
1000 |
1220 |
1220 |
1500 |
1500 |
Motor power(KW) |
0.55 |
0.55 |
0.55 |
0.55 |
0.55 |
0.75 |
1.5 |
2.2 |
3 |
Stirring speed(rpm) |
36r/min |
||||||||
Working pressure |
≤0.09Mpa |
||||||||
Working temperature |
<100°C |
||||||||
Accessories |
Thermometer,safety valve,pressure gauge |
||||||||
