QN-series Vacuum Pressure Reduction Concentration Tanks Equipment

Hangzhou Huihe Machine Facture Co., Ltd.
QN-series Vacuum Pressure Reduction Concentration Tanks Equipment thumbnail-1
QN-series Vacuum Pressure Reduction Concentration Tanks Equipment photo-1
US$ 25,000 - 40,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
hh
Model Number:
hh-0120
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name hh
Model Number hh-0120
Type Other, water treatment
After-sales Service Provided Engineers available to service machinery overseas

Product information:



Introduction:







This device mainly includes concentration can, condenser, gas-liquid separator, cooler and liquid receiving barrel.



The concentration can is of clip-sleeve structure; the condenser is of row-pipe type; the cooler is of coiled type. The device is suitable for the concentration of the material liquid in such industries as pharmacy, food and chemistry, etc, and as well serves for the recycle of alcohol and simple refluence distillation. The contact part of the concentrator and the material is made with the stainless steel, resistant to corrosion and meeting the standard of the GMP.







Function:







This equipment is manufactured of stainless steel, provided a high-pressured water automatically spraying system. It is possible to get in the cooling water to the clamp cover. The transmission spot uses the mechanical seal. And to guarantee the production process safely as well as to conform to the GMP quality specification, we use the explosion proof electrical machinery.



Technical Pramaters:



Model
QN-300
QN-500
QN-700
QN-1000
Evaporation KG/H
70
120
145
195
Volume
300L
500L
700L
1000L
Jacket pressure
0.09Mpa
Vacuum degree
500-620mmHg
Heating area
1.3
1.6
2
2.8
Condensation area
2.4
3
3.5
4
Weigh KG
380
450
630
950
Length mm
1900
2030
2100
2335
Width mm
1100
1200
1300
1520
Height mm
2300
2500
2600
2765

 QN-series vacuum pressure reduction concentration tanks EquipmentQN-series vacuum pressure reduction concentration tanks Equipment
