JGM JC75 with CE and EPA and GOST Series Skid steer loader
Specifications |
|
Rated operating capacity(kg) |
1050 |
Tipping load(kg) |
2100 |
Bucket capacity(m3) |
0.55 |
Operationg weight(kg) |
3500 |
Max. travel speed(km/h) |
12/18 |
Hydraulic pump flow(L/min) |
75/125 |
Fuel tank capacity(L) |
60/90 |
Tires |
12/16.5NHS |
Overall dimensions(mm) |
3560×1900×2050 |
Dimensions |
|
Height at maximum extension(mm) |
4070 |
Height to bucket hinge pin(mm) |
3150 |
Width with bucket(mm) |
1900 |
Track width(mm) |
1500 |
Wheelbase(mm) |
1185 |
Ground clearance(mm) |
260 |
Dump angle |
40° |
Dumping height(mm) |
2450 |
Maximum reach(mm) |
710 |
Rollback at ground |
26° |
Angle of departure |
20° |
Engine |
|
Maker/Model |
Perkins lovol/weichai deutz |
Net power |
75hp/2500rpm |
Type |
4Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
Displacement(L) |
3.9-4.2 |
Standard |
|
Standard bucket |
|
Enclosed operator cab |
|
Hydraulic joystick controls |
|
High-flow hydraulic system |
|
Prehest starting assist system for extreme cold weather |
|
Auxiliary hydraulic couplers |
|
Optional |
|
Cab fitted with a heater as standard |
|
Air conditioner |
|
2-speed transmission system |
|
...
