compact track skid steer loader, JGM TS80 Skid Steer with CE and EPA and GOST Series, engine power 80hp

Specifications

Rated operating capacity(kg)

1200

Bucket capacity(m³)

0.5-0.6

Operationg weight(kg)

4000

Max. travel speed(km/h)

10/20

Hydraulic pump flow(L/min)

75/130

Fuel tank capacity(L)

85

Overall dimensions(mm)

3385×1850×2025

Dimensions

Height to bucket hinge pin(mm)

2920

Width with bucket(mm)

1850

track shoe width(mm)

320

track ground length(mm)

1500

Ground clearance(mm)

200

Engine

Maker/Model

Weichai Deutz

Net power

80hp/2500rpm

Type

4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine

Displacement(L)

3.9

Standard

Standard bucket

Open-type operator cab

Hydraulic joystick controls

Auxiliary hydraulic couplers

Optional

Enclosed operator cab with A/C

High-flow hydraulic system

Attachments:

Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More
