Portable gold sluice box
Introduction to portable gold sluice box
Vibrating sluice box is designed by China Gold Research Institute and improved by us. It is designed with practical mining experience and of efficient concentration for fine heavy minerals in the sand.
Our vibrating sluice box could be used on land and dredger. It is less restricted by the terrains and working conditions compared with centrifugal type gold concentrator. Although its recovery efficiency is a little low than gold centrifugal concentrator, it is less expensive and easier to operate.
Technical parameter for portable gold sluice box
Parameter Model | YLG20 | YLG30 | YLG45 |
Capacity(T/h) | 15-20 | 25-30 | 35-45 |
Feeding Particle Size(mm) | ≤6mm | ≤6mm | ≤6mm |
Water Consumption(m3/h) | 50-60 | 80-100 | 110-150 |
Power(kw) | 1.1 | 1.5 | 2.2 |
Dimension(L*W*H)(m) | 1.2m*3.8m*0.8m | 1.5m*3.8m*0.8m | 1.8*3.8*0.8m |
Pictures of our portable gold sluice box
v
ox
Application of our sluice box
We will design the most suitable gold mining machine/gold dredger as a professional manufacturer.
