Benefication placer gold recovery equipment
1.Brief Introduction to benefication placer gold recovery equipment
---The pulsating sluice box is also called instigating sluice box and agitating sluice box.
---It is specially developed for gold separating and mining according to the mining practice of placer gold. This kind of gold sluice box is researched Chinese gold research institute and improved by us for many years. Over 1000 units of the machine has been sold out which are in application in 10 different countries and appreciated highly by our customers from Bolivia, Indonesia, and Australia,Canada,South Africa,Malasia.Compared with centrifugal concentrator,it is much more cheap and easier to be operated.
2.Specification for benefication placer gold recovery equipment
| Capacity | Power | Water Consumption | Recovery rate | Dimension | Feeding Particle Size | Gold size |
| 30 tons per hour | 1.5kw | 40 m3 per hour | 80% | 3.5m×1.5m | ≤8mm | under 8mm |
3.Pictures and Applications of the benefication placer gold recovery equipment
Single Pulsating sluice box( instigating sluice box/agitating sluice box )
Semi-completed vibrating sluice box
Our patent gold recovery equipment-----Dual pulsating sluice boxes
Pulsating sluice box used on Land gold washing plant. We add the gold mining grass under it to raise the recovery rate.
Centrifugal gold separating machine which can discharge the gold concentrates automatically.
Pulsating sluice box used on Dual Jet Suction Gold Dredger
The gold concentrates will further be separated by gold shaking table or gold pan.
| Item | Coarse sand surface of table | Fine sand surface of table | Ore slime surface of table | |
| Dimension | Length (mm) | 4450 | 4450 | 4450 |
| Transmission end width (mm) | 1855 | 1855 | 1855 | |
| crude ore width (mm) | 1546 | 1546 | 1546 | |
| Max. feeding size (mm) | 2 | 0.5 | 0.15 | |
| Feed amount (t/h) | 30-50 | 41567 | 15-25 | |
| Feed density (%) | 25-30 | 20-25 | 15-25 | |
| Stroke (mm) | 16-22 | 41594 | 41502 | |
| Frequency ( f) | 45-48 | 48-53 | 50-56 | |
| Water quantity added(t/h) | 80-150 | 30-60 | 41564 | |
| Horizontal obliquity (°) | 2°30′-4°30′ | 1°30′-3°30′ | 1°-2° | |
| Longitudinal obliquity (%) | 1.4 | 0.92 | -- | |
| Dressing Area (m2) | 7.6 | 7.6 | 7.6 | |
| Cross-section Shape of table | Rectangular | Saw tooth | triangle | |
| Motor Power (kw) | 1.1 | 1.1 | 1.1 | |
We are the professional gold mining equipments manufacturer.Besides of pulsating sluice box, we have many kinds of gold and diamond separating machines.Please share with us more information about your requirements, we will design and provide the most suitable equipments for you.
