China Gold Extraction Equipment
SPECIFICATIONS
Item | Specification |
Trommel Screen | |
Size | Inner Diameter 1.1m, |
Outer Dimater1.4m | |
Length 5m | |
Trommel | Length2m Diameter1.1m |
Screen | Length 2.9mInner |
Diameter1.2 | |
Outer Dimeter1.5m | |
RPH | 18—20r/h |
Gearbox | Type 400 |
Power | 18.5KW |
Hopper | |
Size | 2800mm×2800mm |
Hopper Steel Plate Thickness | 6mm |
Hopper Support Frame | 114 Round Steel Pipe |
Pulsating Sluice Box | |
Size | 3300mm×1300mm |
Power | 1.1kw |
Capacity | 25-30ton/h |
Ratio of Sands | 30% |
Gearbox | Type 200 |
Particle Size | <8mm |
Water Supply System | |
Pump | 150-125-315 |
Flow | 200m³/h |
Head | 32m |
Power | 30kw |
Diving Pump | 4Kw |
Conveyor Belt | |
Size | Length10m Width6m |
Power | 7.5kw |
Gearbox | Type 350 |
Diesel Generator | Diesel Engine |
Generator | 75kw |
PRODUCT FEATURES OF CHINA GOLD EXTRACTION EQUIPMENT
1.Could be used to mine gold mixed with sand in palaeochannel, palaeo-riverbed, alluvial placer, tailing after ball milling, and diamond and zirconium in raw ore.
2.Iron ore needs to be retrieved first with magnetic separator if the percentage is high in the raw ore, then gold, diamond, zirconium will be concentrated, or the effectiveness will be affected.
3.This set of mining equipments are composed of several gravity concentrators. The concentration ratio could reach as high as 1:1000, and the recovery efficiency about 90% after series of separation.
COMPANY INTRODUCTION
Qingzhou Yongli Mining and Dredging Machinery Co.,Ltd, located in Qingzhou City---one of the Nine Ancient Cities in China, is a leading company of China mining equipments. We are the professional manufacturer who has been dedicated in R&D, designing, producing and providing assembly and testing service.
We always insist on the principles of honest, mutual benefit, co-development and welcome to our factory for investigation and discussion.
1.We have our own plant and enginner ,we will design the gold washing plant according to your situation and requirements.
2.We have rich experience in export,our customers from all over the word ,such as Ghana,Bengal and so on.
3.We have petent,we are alone in the China ,even in the world.
4.We have a great group,we will give you a most sincere service.
Market and future are our unremitting pursuit, Yongli people forge ahead, and are commited to provide the best products to the whole world. We stand on the local, and put our eyesight on global market. We have been dedicated to create the first brand in this industry.
1. Yongli company signs a long-time after-sale service agreement with customers.
2. We provide rational and practical design according to customers' request.
3. We send engineers to assemble and test the machine within the period as agreed in the contract.
4. Within warranty period, we provide free repair if quality problems emerge.
5. We provide training of operation and maintenance for customers as agreed in the contract.
6. We supply high quality accessories in low price.
7. We make an excellent filing of customers for long-term following-up service.
WELCOME TO CONTACT US FOR FURTHER DISCUSSION AND DREDGER COOPERATION!
