China Iron Sand Ore Screening Dredger Ship Land Use
- Qingdao
You May Like
-
River Sand Iron Ore Sieving Equipments High Efficiency Boat
-
Iron Ore Screening Equipments Land Use Boat
-
River Sand Iron Sieving Equipments With High Efficiency
-
River Sand Iron Sieving Equipments High Efficiency
-
China 8 Inch Iron Sand Ore Dredging Machine
-
Diesel Engine Driven Pump Sand Iron Dredger for Iron Ore Sand Processing
Product Details
| Condition | New | Type | Flotation Separator | |
| Production Capacity | 40-280 t/h | Place of Origin | Shandong, China | |
| Brand Name | Yuanhua | Model Number | YH-B-S | |
| Voltage | 240 | Power(W) | 3-11 KW | |
| Dimension(L*W*H) | As design | Weight | 10t-45t | |
| Certification | ISO 9001:2008 certification |
Product Description
River sand iron sieving equipments
The sand , mixed with water, goes through a sieve to screen our gravels, and then falls into the tank with homogenizing board. Diluted and washed by water again, the sand enters into magnetic area on the roller. High grade iron sand is absorbed on the surface of the roller and transported to the washing unit. After washing out the useless sand, the iron sand is transported to selecting unit. The higher grade iron sand will be washed into the collecting tank and the nonmagnetic sand enters into the tailings tank.
Parameters
Type | Roller Dia. (mm) | Roller Length (mm) | RPM | Particle Size (mm) | Working Capacity (t/h) | Power (kw) |
B0918 | 900 | 1800 |
| 3-0 | 40-60 | 3 |
B0921 | 900 | 2100 |
| 3-0 | 45-60 | 3 |
B0924 | 900 | 2400 |
| 3-0 | 45-70 | 4 |
B1018 | 1050 | 1800 |
| 3-0 | 50-75 | 5.5 |
B1021 | 1050 | 2100 |
| 3-0 | 50-100 | 5.5 |
B1024 | 1050 | 2400 |
| 3-0 | 60-120 | 5.5 |
B1218 | 1200 | 1800 |
| 3-0 | 80-140 | 5.5 |
B1224 | 1200 | 2400 |
| 3-0 | 85-180 | 7.5 |
B1230 | 1200 | 3000 |
| 3-0 | 100-180 | 7.5 |
B1530 | 1500 | 3000 |
| 3-0 | 170-280 | 11 |
