Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Casting Machinery > HJ012 Serial Motor Stator Clamping Hydraulic Press

HJ012 Serial Motor Stator Clamping Hydraulic Press

Name: HJ012 Serial Motor Stator Clamping Hydraulic Press
Brand: Shengli
SKU: 141333334
Availability: InStock

Huzhou Machine Tool Works Co., Ltd.

HJ012 Serial Motor Stator Clamping Hydraulic Press thumbnail-1

HJ012 Serial Motor Stator Clamping Hydraulic Press photo-1

US$ 10,000 - 40,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

Shengli

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name Shengli

Model Number HJ012

Voltage 380v, 220 v

Power(W) kw

Dimension(L*W*H) mm

Weight Depend on Detail Model

Certification CE, ISO, SGS

Warranty One Year

After-sales Service Provided Engineers available to service machinery overseas

Application & Feature

The HJ012 series, vertical four-column type, is specialized for clamping the motor-stators. Actions execute clamping fixture ascent, iron-core positioning, tension, compacting, rolling, clamping, and reset all above actions.

Optional of three operating modes of inch, manual and semi-automatic. Each piston stroke is adjusted and limited by a travel limit device.

With the features of reliability and high efficiency, it's the ideal solution for electric-motor manufacture applications.

Main Technical Data

Technical Parameter		Unit	HJ012-40B	HJ012-63A	HJ012-63A	HJ012-100
Nominal Force	Main Cylinder	KN	400	630	630	1000
	Rolling Cylinder		50	77	77	120
	Tension Cylinder		35	50	50	60
	Pushing Force		/	/	54	/
Stroke	Main Cylinder	mm	320	350	350	630
	Rolling Cylinder		300	500	500	630
	Positioning Cylinder		240	430	/	/
	Tension Cylinder		45	70	70	100
	Pushing Force		/	/	600	800
Speed	Ram Descent	mm/s	20	125/26	125/26	100/12
	Ram Ascent		50	125	125	90
	Roll-beam Ascent		40	50~55	50~55	25
	Roll-beam Descent		50	/	/	40
Opening Table Size	Left to Right	mm	450	570	570	900
Opening Table Size	Front to Back	mm	400	500	500	900
Max.Distance between Table and Ram		mm	740	785	785	1000
Max.Distance between Table and Roll-beam		mm	300	500	500	750
Table Height above Floor		mm	580	750	500	750
Suitable Range		Motor Model	Y80-Y160 Y-Serial Motor	Y160-Y225 Y-Serial Motor	Y160-Y225 Y-Serial Motor	Y200-Y2-355 Y-Serial Motor
Overall Size	Front to Back	mm	1395	1700	2200	2220
	Left to Right		1627	2050	2050	2800
	Height above Floor		3115/2812	3940/3440	3690/3190	3850/3275
Motor Power		KW	5.5	5.5	5.5	7.5

1.Specifications mentioned above are subject to any change without notice.

2.The products can be tailored as customer's desire or provide a full set for electric motor manufacture.

FAQ ABOUT HYDRAULIC PRESSES

Does welded beam easy deformation?

We treat it with tempering treatment to reduce internal stress.Besides, we also make casting beam.

The oil cylinder is important part,what if it broke?

We use forging cylinder which is forged by one 45# round steel,no welded.The broke rate is almost zero.

What about the electric system?

We use PLC electric control system with less line,easy maintenance and can programmable.

If part of the machine broke,does it easier to buy it in our country?

We can use customer appointed accessories if necessary.

Do you provide after service?

We provide technical service for life.

we are manufacturer of hydraulic press more than fifty years and can manufacture non-standard hydraulic press as your need( such as large worktable,deep slider stroke,multiple cylinder,high speed,double acting...)
