Product Details
Condition: | New | Type: | Flotation Separator | Production Capacity: | 20T/H |
Place of Origin: | Shandong, China | Brand Name: | hengchuan | Model Number: | HC-10 |
Voltage: | The contract shall prevail | Power(W): | 4KW | Dimension(L*W*H): | 4400*1400*2000mm |
Weight: | The contract shall prevail | Certification: | One year giant (guarantee) except the quick wear parts | Warranty: | One year giant (guarantee) except the quick wear parts |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Contract packaging listed.
Product Description
Mobile Gold Mining Trommel Machine
Company profile
Shandong Hengchuan Ore Machinery Co. , Ltd, established in 2002, is leading ore machinery in china. Company covers area of 20000 square meters.
Our main products :Placer Gold Mining Machine ,Magnetic Separator ,Sand Mining and Washing Machine, Mining Dredgers ,Sand Barges, Particular Vessels, etc. They have been sold not in domestic market, but export to more than thirty foreign countries, like Philippines, Malaysia, North Korea , Mongolia, Cameroon, South Africa, Ghana, Brazil, etc.
Introduce of movable gold mining machine :
The trommel screen provides a simple, efficient and economical solution to upgrade a wide rang of materials and optimize the subsequent process steps of recovery. This method of screening helps to reduce operating and investment cost and to enhance product quality with rapid and large volume processing.
The material is then passed on to the downstream process equipment which can be in various forms such as centrifugal concentrator, spirals, jigs etc.
Technical parameter of movable gold mining machine :
Modle | Capacity T/h | Power kw | Water m³/h | Ore size mm | Recovery % |
HC-100 | 100 | 45 | 200 | ≤100 | ≥90 |
HC-150 | 150 | 64 | 300 | ≤100 | ≥90 |
HC-200 | 200 | 45 | 400 | ≤100 | ≥90 |
HC-250 | 250 | 45 | 500 | ≤100 | ≥90 |
Working principle of movable gold mining machine :
1) Input of raw materials through heavy equipment
Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by the strong water pressure of the shower equipped in the hopper.
2) Selection and cleaning of raw materials
Raw materials will be cleaned and selected by the rotation of trommel screen and, by watering of the shower inside, run into the gold dust separate panel.
3) Collecting of gold dust separated
Soil and sands with lighter specific gravity will flow away but gold dusts with greater specific gravity will be staying in the gathering mat to be collected.
Application of movable gold mining machine :
The trommel Screen is widely used for screening and classifying mineral materials, such as metallurgy, mining, chemical, coal, building materials, abrasives, and other industries.
1.Quarry: suitable for screening and classifying gravel, clay, mountain meal, sand, etc.
2.Coal Industry: suitable for screening and classifying lump coal, coal dust, coal washing, etc.
3.Chemical, Mineral-selecting Industry: suitable for grading and classifying lump, powder substance, etc.
4. Metallurgy, construction and other industries.
5. Mining: alluvial gold, placer gold sand gold ,etc.
Features of movable gold mining machine :
1 Include single, double, and muti layer type
2 Strong processing ability
3 Easy maintenance and long life
4 High-efficient and power-saving
5 Simple and various feeding ways
6 non-pollution and low noise
7 Deputed quality with ISO:9001
Working diagram
Contact Us
Name | Andy |
| |
Company Name | Shandong Hengchuan Ore Machinery Co.;Ltd |
Address | Mihe Industrial zone,Qingzhou City,Shandong province |
Company Profile
Qingzhou Hengchuan Ore Machinery Co.,ltd,was established in 2002,a leading ore machinery manufacturer in China,covering an area of 20000 square meters,have 6 engineers,20 technicians and 100 workers.
Our main products:Gold Mining Machinery,Magnetic separators and all kinds of mining dredger etc.Our main market is domestic,Africa and Southeast Asia,such as Cameroon,Ghana,Mali,Zimbabwe,Malaysia,Indonesia and Philippines etc.
Cutter suction dredger is widely used in dredging engineering.The rotating cutting head in the front of the suction pipe can stir slurry,then dredging pump suck the slurry through the suction pipe,then through the discharge pipe to the mud yards.Dredging, transportation and discharge is a whole series work.So the cutter suction dredger is an efficient and economic dredger.We start to manufacture the cutter suction dredger from 2005,gradually accumulated rich experience in this field.
Development History:
A).Established Magnet Research Institute in 2004,successfully developed the high gradient magnetic separator to 12000-22000GS.
B).Cooperated with Shandong Gold Group and doubled the sales scale.
C).Developed STL-120 gold centrifugal concentrator in 2008.
D).Mature dredger products in 2009.
E).Developed successfylly knelson smiliar type automatic discharge type gold centrifual concentrtor and produced them in large quantity for sellling.
F).Established Shandong Hengchuan International Trade Co.,Ltd in 2015.
Enterprise Spirit -eternal integrity
Enterprise Purpose-to consistently exceed customers' expectations
Core Values-innovation and leading the future
Service Concept- to create value for customers
Development Concept - Quality is life; innovation is the driving force
Corporate Vision- the world leading supplier of magnetic separation equipment
