Specifications
Pipelayer 30t PMGY301.Good quality and low price.
2.World famous brand,and professional service
3.Max.lifting capacity:30t
Pipelayer 30t PMGY30
PMGY 30 full hydraulic sideboom adopts self-developed specialized chassis for full hydraulic sideboom, electric/hydraulic single control handle, imported famous brand hydraulic components, wide-narrow combined tracks, which possess advantages of low volume, reasonable structure, low ground pressure, high adaptability, sooth & convenient operation, excellent jiggle performance etc.
Item |
Main parameters |
|||
Model |
PMGY30 |
|||
Max lifting capacity t |
30 |
|||
Rated lifting capacity t |
25.5 |
|||
Overall weight ( approximate ) t |
27 |
|||
Delivery dimension ( L×W×H ) mm |
5010×3200×3290 |
|||
Transportation weight of main set kg |
21800 |
|||
Average ground pressure kPa |
58.6 |
|||
Min ground clearance mm |
436 |
|||
Max climbing capability ° |
20 |
|||
Ambient conditions |
Ambient temperature range -20 °C -40 °C ; Altitude below 3000m |
|||
Engine |
Model |
Cummins 6BTA5.9 |
||
Rated power/rated rotating speed kW/rpm |
125/2300 |
|||
Traveling system |
Chassis |
Special designed chassis for sideboom |
||
Operational mode |
Hydraulic handle |
|||
Theoretical travel speed |
gear I km/h |
0 ~ 2.3 infinite speed adjustable |
||
gear II km/h |
0 ~ 5.3 infinite speed adjustable |
|||
|
Length of track on ground mm |
3070 |
|||
Track width mm |
910 left 560 right |
|||
Number of track rollers |
7×2 ( S/F 5×2 pieces , D/F 2×2 pieces ) |
|||
Hoisting system |
Luffing type |
Wire rope luffing |
||
Operational mode |
Hydraulic handle |
|||
Main boom |
Length mm |
7500 |
||
Max lifting height mm |
6590 |
|||
|
Main boom luffing angle ° |
0 ~ 85 |
|||
Luffing time s |
Boom down : 24 / boom up : 24 |
|||
Hook speed (6MF) m/min |
0 ~ 13 |
|||
Applied standards |
Q/GDR 008-2008 , ISO8813 - 92 |
|||
