Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Pipe Making Machine > 70tons Pipe Layer
US$ 39,800 - 79,800
MOQ: 1 Unit
Key Specifications
Get Latest Price
Pipe Material:
Stainless Steel
Place of Origin:
Shandong, China
Brand Name:
Shantui
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Pipe Material
Stainless Steel
Place of Origin
Shandong, China
Brand Name
Shantui
Model Number
SP70Y
Specifications
1. Equipped with advanced international technology2. Hydraulic pilot control system
3. Excellent quality & competitive price
Piper Layer SP70Y
The SP70Y pipe layer is equipped with advanced international technology to provide load feedback and prevent overloading while working on pipe laying projects. With a hydraulic pilot control system, the operations of working devices such as the hook and lifting arm are integrated into a single lever, which is capable of precise, sensitive performance. The machine has been designed to specially measure operating functions in order to prevent overturning or rolling over.
| Product model: | SP70Y |
| Engine model: | Cummins NTA855-C360 |
| Rated power(kw/rpm) | 235/2000 |
| Max.lifting weight(t): | 70 |
| Operating weight(kg): | 47500 |
| L*W*H(mm): | 5560*3700*2395 |
| Min.turning radius(mm): | 3950 |
| Track gauge(mm): | 2380 |
| Ground length(mm): | 3620 |
| Track shoes width(mm): | 860(alternative) |
| Ground pressure(Mpa): | 0.086 |
| Max lifting height(mm): | 6550 |
| Boom swing amplitude(m): | 1.2-7.2m |
| Hook length(m): | 0-6.0 |
| Boom length(m): | 7.3(9.0) |
