Home > Manufacturing & Processing Machinery > Crane > Other Cranes > 35ton Rough-terrain Crane

35ton Rough-terrain Crane

Name: 35ton Rough-terrain Crane
Brand: ZOOMLION
SKU: 141324884
Availability: InStock

US$ 250,000 - 260,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Rated Lifting Moment:

1340kN.m

Max. Lifting Load:

35T

Contact Supplier Request Quote Chat Now

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Rated Lifting Moment 1340kN.m

Max. Lifting Load 35T

Max. Lifting Height 46m

Place of Origin Hunan, China

Brand Name ZOOMLION

Model Number RT350

Specifications

1.Dongfeng Cummins or Original Cummins
2.Kessler axle, Hangchi transimission
3.Germany Hismann Limiter

1.The machine adpot four wheel drive and four wheel steering, so the machine have three kind moving control, two wheel steering, four wheel steering and crabbing.

2.Short wheelbase design make the machine very convinient in narrow space, minimum turning diameter.

3.The machine passed the TUV inspection, can meet the America standard.

Item	No.	Specification	Unit	Value
Working performance specification	1	Max. rated total lifting capacity ×working radius	kg.m	35000×3.0
	2	Max. load moment of basic boom	kN.m	1340
	3	Max. load moment with max. main boom length	kN.m	902
	4	Max. lifting height of main boom	m	34
	5	Max. lifting height of fly jib	m	48.5
Dimension specification	6	Overall dimensions(L×W×H)	mm	11840×2980×3600
	7	Outrigger span(portrait×transy)	mm	6810×6800
	8	Main boom length	mm	9800~31000
	9	Fly jib length	mm	9088~15028
	10	Main boom angle°	°	-3~78
	11	Swing range		360° Continuing
Working speed	12	Max. speed of single rope on main winch m/min	m/min	150
	13	Extend time of Boom	s	70
	14	Retraction time of Boom	s	75
	15	Rising time of boom	s	46
	16	Laydown time of boom	s	47
	17	Slewing speed	r/min	0~2.5
Hydraulic system	18	Rated working pressure	MPa	27
	19	Rated working flux	L/min	400
	20	Volume of Hydraulic oil tank	L	600
Mass specification	21	Deadweight of crane in traveling condition	kg	32000
	22	Front axle load	kg	15060
	23	Rear axle load	kg	16910
Traveling specification	24	Max. traveling speed (Advance/back)	km/h	38/15
	25	Wheelbase	mm	3820
	26	Wheel track(Front/Rear)	mm	2444
	27	Max. grade ability	%	110
