37ton excavator XE335C
Model |
Unit |
XE370CA |
|
Operating weight |
kg |
36600 |
|
Standard bucket capacity |
m³ |
1.4~1.8 |
|
Engine |
Engine Model |
/ |
ISUZU AA-6HK1XQP |
Direct injection |
/ |
√ |
|
Four strokes |
/ |
√ |
|
Water cooling |
/ |
√ |
|
Turbo charged |
/ |
√ |
|
Air to air intercooler |
/ |
√ |
|
No. of cylinders |
/ |
6 |
|
Rated power/speed |
kw/rpm |
184/2000 |
|
Max. torque/speed |
N.m |
872.8/2000 |
|
Displacement |
L |
7.79 |
|
Main Performance |
Travel speed |
km/h |
5.4/3.2 |
Swing speed |
r/min |
9.7 |
|
Max. gradeability |
/ |
≥35 |
|
Ground pressure |
kPa |
66.6 |
|
Max.Bucket digging force |
kN |
242 |
|
Max.arm crowd force |
kN |
183 |
|
Max.traction force |
kN |
285 |
|
Rate flow of main pump |
L/min |
2×280 |
|
Max pressure of prime relief valve |
MPa |
31.5/34.3 |
|
Max pressure of travel system |
MPa |
34.3 |
|
Max pressure of swing system |
MPa |
27.5 |
|
Max pressure of pilot system |
MPa |
3.9 |
|
Oil Capacity |
Fuel tank capacity |
L |
630 |
Hydraulic tank capacity |
L |
320 |
|
Engine lubrication |
L |
28 |
|
Dimensions |
Overall length |
mm |
11246 |
Overall width |
mm |
3190 |
|
Overall height |
mm |
3350 |
|
Overall width of upperstructure |
mm |
2960 |
|
Track length |
mm |
5035 |
|
Overall width of undercarriage |
mm |
3190 |
|
Crawer width |
mm |
600 |
|
Track length on ground |
mm |
4040 |
|
Crawer gauge |
mm |
2590 |
|
Clearance under counter weight |
mm |
1197 |
|
Ground clearance |
mm |
500 |
|
Min.tail swing radius |
mm |
3450 |
|
Work Scope |
Max. digging height |
mm |
10423 |
Max. dumping height |
mm |
7275 |
|
Max. digging depth |
mm |
7139 |
|
8inch horizontal digging depth |
mm |
6954 |
|
Max. vertical wall digging depth |
mm |
6545 |
|
Max. digging reach |
mm |
10887 |
|
Min. swing radius |
mm |
4424 |
|
