70ton Excavator

Name: 70ton Excavator
Brand: XCMG
SKU: 141324698
Availability: InStock

US$ 18,000 - 660,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

XCMG

Model Number:

XE900C

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number XE900C

Condition New

Moving Type Crawler Excavator

Maximum Digging Height 12060mm

Maximum Digging Depth 7250mm

70ton excavator

Model		Unit	XE900C
Operating weight		kg	88800
Standard bucket capacity		m³	4.0~5.0
Engine	Engine Model	/	Cummins QSX15
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	√
	No. of cylinders	/	6
	Rated power/speed	kw/rpm	395/1800
	Max. torque/speed	N.m	2365/1400
	Displacement	L	15
Main Performance	Travel speed	km/h	3.9/2.7
	Swing speed	r/min	7.3
	Max. gradeability	/	≥30
	Ground pressure	kPa	115
	Max.Bucket digging force	kN	479
	Max.arm crowd force	kN	368
	Max.traction force	kN	629
Hydraulic System
	Rate flow of main pump	L/min	2×521
	Max pressure of prime relief valve	MPa	31.4/34.3
	Max pressure of travel system	MPa	34.3
	Max pressure of swing system	MPa	30
	Max pressure of pilot system	MPa	3.9
Oil Capacity	Fuel tank capacity	L	1225
	Hydraulic tank capacity	L	755
	Engine lubrication	L	48
Dimensions	Overall length	mm	13570
	Overall width	mm	4550
	Overall height	mm	5090
	Overall width of upperstructure	mm	3350
	Track length	mm	5840
	Overall width of undercarriage	mm	4550
	Crawer width	mm	750
	Track length on ground	mm	4545
	Crawer gauge	mm	2960/3500
	Clearance under counter weight	mm	1680
	Ground clearance	mm	880
	Min.tail swing radius	mm	4700
Work Scope	Max. digging height	mm	12060
	Max. dumping height	mm	8070
	Max. digging depth	mm	7250
	8inch horizonal digging depth	mm	7100
	Max. vertical wall digging depth	mm	4200
	Max. digging reach	mm	12330
	Min. swing radius	mm	5200
