US$ 1 - 10
MOQ: 2 Sets
Key Specifications
Get Latest Price
Brand Name:
S
Model Number:
S
Payment & Shipping
Payment Methods:
Port of Shipment:
SH
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
S
Model Number
S
| type | ZLY-910F | ZLY-912DH | ZLY-915DF | ZLY-916DF | ZLY-918DF | ZLY-920 | ZLY-928 |
| Rated load mass(kg) | 1000 | 1400 | 1500 | 1600 | 2800 | 2000 | 2800 |
| Rated Bucket Capacity(m³) | 0.35 | 0.5 | 0.6 | 0.7 | 1.2 | 1.0 | 1.2 |
| Quality Machine(kg) | 2480 | 2700 | 3400 | 3650 | 6500 | 5600 | 6000 |
| Engine Model | L28 | 485 | 4100 | 4102 | 4102 | 4105 | 4108 |
| Rated(kw) | 19.42 | 26 | 44 | 48 | 49 | 53 | 60 |
| Load Height(mm) | 2750 | 2750 | 3000 | 3200 | 3000 | 3100 | 3100 |
| Load Distance(mm) | 900 | 1200 | 1200 | 1200 | 1200 | 920 | 1200 |
| Tire Model | 750-16 | 825-16 | 1200-16 | 1490-16 | 14/90-16 | 16/70-20 | 17.5-25 |
| Max.Gradeability(º) | 30º | 30º | 30º | 30º | 30º | 30º | 30º |
| Drive Type | four-wheel | four-wheel | four-wheel | four-wheel | four-wheel | four-wheel | four-wheel |
| Brake Type | front-rear hydraulic disc | front-rear hydraulic disc | front-rear hydraulic disc | front-rear hydraulic disc | front-rear hydraulic disc | front-rear hydraulic brake mode | front-rear hydraulic brake mode |
| Movable arm lifting time(s) | 4.5 | 4.5 | 4.0 | 4.0 | 5.5 | 5.5 | 5.5 |
| Dumping time(s) | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 |
| Movable arm descending time(s) | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| physical dimension(mm) | 5000x1600x2450 | 5000x1600x2450 | 5500x1600x2800 | 5600x1650x2650 | 5600x1600x2650 | 6900x1900x2850 | 6990x2420x3000 |
