FH6 light diesel engine outboard motor
- 0 per Month
- s
- Industrial 2/2.5/3 inches High Pressure Coanda Aluminum Alloy Air Knife
- Factory Customize Adjustable Drying Air Knife For Turbo Blower
- Drying And Cleaning System Aluminum Alloy Air Knife Outlet Width Adjustable Air Nozzle
- Aluminium alloy air compressed air knife for drying and blowing
- Aluminum Alloy Nozzle Compressed Air Drying Windjet Air Knife
- Aluminium alloy Low flow air knife for use with compressed air
Product Details
Place of Origin: | Guangdong, China | Brand Name: | . | Model Number: | . |
Product Description
MODEL | FH6 |
CYLINDER | 1 |
BOREXSTROKE | 78X62MM |
DISPLACEMENT | 296ML |
MAX POWER | 4.4KW |
RATED POWER | 4KW |
RATED SPEED | 3600RPM |
SPEED RANGE | 13:24 |
METHOD OF EXHAUST | EXHAUST BY PROPELLER |
METHOD OF LUBRICATION | LUBRICATION BY GEAR PUMP |
METHOD OF COOLING | CYLINDER HEAD, CIRCULATING WATER |
METHOD OF STARTING | MANUAL OR ELECTRIC START |
TIP PROGRESSION | 6 |
GRADE OF FUEL | GRADER O IN SUMMER AND -10 IN WINTER |
GRADE OF LUBRICATION OIL | SAE10W-30/40 (ABOVE GRADE CC) |
GRADE OF LUBRICATION OIL | API GL5: SAE80-90 (300ML) |
IN GEAR CASE | |
TRANSOM LENGTH | 562MM |
LENGTH | 900MM |
WIDTH | 425MM |
HEIGHT | 1270MM |
WEIGHT | 63/68KG |
PROPELLER | 3X9.25" X 7" |
STOWAGE WEIGHT OF SHIP | 800KG |
THE FEATURES OF 4-STROKE DIESEL OUTBOARD MOTORS
Feature 1: Good safety performance.
The use of higher ignition-point diesel fuel can avoid the risk of exploding caused by using the lower ignition-point gasoline fuel.
Feature 2: Outstanding economical performance.
The use of the advanced four stroke vertical shaft and direct injection diesel engine can save large amount of expensive fuel, consequently saving large costs for you or your enterprise. The fuel consumption rate of FH4-4HP, FH6-6HP, FH9-10HP diesel outboard motors separately are 1.1L / h, 1.5L / h, 2.2L / h, it is only 1/3 of two-stroke petrol outboard motors with same power, is only 1 / 2 of four-stroke petrol outboard motors with same power.
Feature 3: Strong power performance
With the more remarkable power performance and the stronger torque properties, the four stroke diesel engine is able to meet the demand of higher speed with heavy loads. As the diesel outboard motors has strong drive and good torque characteristics, the weight of FH4-4HP, FH6-6HP, FH9-10HP diesel outboard motors is equal with the 8-9.8HP ,15-18HP ,25-30HP petrol outboard motors.
Feature 4: Lasting and durable performance
Though the full loaded sea test for 500hours, it certify that the reliable and durable power with mature technology and the multi-layered anticorrosion methods can guarantee the reliable and long-lasting performance.
Update Date:2011-8-5 2:15:02
