4LZ-1.4 combine harvester 2014 hot sell with good quality China supplier agriculture machinery

Name: 4LZ-1.4 combine harvester 2014 hot sell with good quality China supplier agriculture machinery
Brand: JYB
Price: Negotiable

FOB Price

Negotiable / Set

3 Sets(Min.Order)

Supply Ability 0 per Month

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Combine Harvester	Usage:	Grain Harvester
Place of Origin:	Sichuan, China	Brand Name:	JYB	Model Number:	4LZ-1.4
Dimension(LWH):	4450x1790x2480	Weight:	2150kg	Certificate:	Other
Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Specifications

Easy for operation and maintenance.
It is a safety and energy-saving machine.
Threshing loss less than 3%, high purity 98%.

Model:	4LYZ-1.4 Combine Harvester	Application:	Grain, Wheat, Rape Seed.
Type:	Full-feed, Track Combine	Safety & Handling:	See Product Brochures.
Make:	JinYang Bao	Occupation:	Manufacturer

Product Description:	4LYZ-1.4 combine with excellent performance in different crops and different field conditions,
	the machine is easy for operation and maintenance, it is a safety and energy-saving machine.
Quality System:	Production Plant Accredited to GB/T 19001-2008 / ISO9001 :2008.
Packing:	Strong standard export package suitable for long distance transportation.

Specification:

Overall Dimension	Length×Width×Heights ( mm ): 4450×1790×2480

Weight (kg)	2150

Feeding Capacity( kg/s )	1.4

Harvesting Capacity(hm²/h):	0.1-0.4

Engine	Engine Model: SL3105ABN;
	Rated Power ( kw/hp ): 42.2/57.4
	Engine Type: Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel.
	Rated Rotation Speed (r/min) : 2600
	Fuel Tank Capacity ( l ): 47

Driving System	Crawlers: Track Gauge( mm ): 850; Width×ground contact length ( mm ): 350×1480
	Crawler Steering Radius ( mm ): left turn 2750; right turn 2750
	Minimum Ground Clearance (mm): 210
	Type of Gearbox: Mechanism + HST(3F, 3R)
	Theoretical Operating Speed ( km/h ): 0~4
	Type of Brake: By Foot.
	Steering: Clutch and Brake.

Cutting header	Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5
	Height Adjustment: Hydaulics.
	Cutting Bar Length ( mm ): 1400
	Type of Cutting Bar Auger: Screw Conveying.
	Type of Blade: V Type / Left and Right.
	Rape Seed Extension: Optional

Threshing & Separating	Threshing System: Spiked Tooth Axial Flow
& Cleaning System	Main Threshing Cylinder Size Diameter × Length ( mm ): 443×958
	Assistant Threshing Cylinder Size Diameter × Length ( mm ): 443×408
	Reshresher: Blade Rotation.
	Concave Sieve: Grid × 2
	Blower Fan: Type: Swirl; Diameter( mm ): 300; Nos: 2

Grain Storing	Option 1: Grain Tank with Unloading Auger, Capacity ( l ): 778
	Option 2: Manual Operation.
