Home > Manufacturing & Processing Machinery > Mining Machinery > Dredger > Submersible Pump Sand Dredger

Submersible Pump Sand Dredger

Submersible Pump Sand Dredger photo-1
Submersible Pump Sand Dredger photo-2
Submersible Pump Sand Dredger photo-3
US$ 15,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Submersible Pump Sand Dredger
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Submersible Pump Sand Dredger
Power Type Diesel
Dredging Depth 30 m
Draught 80 cm
Brand Name KeDa
Model Number KDSX200-10
Dimension(L*W*H) 14*4.2*1.4m
Weight 15T
Certification ISO9001/CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Submersible Pump Sand Dredger







Product Description



Feature:

1. Economic and high sand dredging efficiency



2.Portable to move



3.Easy to operate with reliable quality



ModelKDSX200-10KDQSB200-5
Dredger Body
Dimention (m) L*W*H14*4.2*1.4m12*4.7*1.2
Float
Pontoon
Side pontoons 2sets11.5*1.0*1.4m11*1.25*1.2
Main pontoon 1set8.5*2.25*1.4m8*2.25*1.2
MaterialCCSACCSA
Total weight T3020T
Pump model6/4”D-GZJQ300-20-37
Rotation speed(r/m)1150980
Dredging data
Standard dredging depth   8-10m5M
Standard discharge distance500m50M
Max.dredging depth(m) (optional)10m8M
Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows)600m70M
Max.standard dredging capacity   m3/h50m3/h50-70m3/h
Min.clean water flows(standard dredging depth and Max.discharge distance)250m3/h300m3/h
Suction pipe diameter(mm)200
Discharge pipe diameter(mm/inch)200200mm


Submersible Pump Sand Dredger

Submersible Pump Sand Dredger



Submersible Pump Sand Dredger

Submersible Pump Sand Dredger





Our Services



1. Design

Ourdredgers are designed by senior engineer, who have specialized in shipbuilding and dredging work for many years. It guaranteesthat our dredgers are well-designed and of high-quality.

2. Good processing & Ex-work testing

Every dredger is built by skilled workers and inspected strictly to assure its high quality. Each finished dredger will be tested in testing center to make sure it works smoothly when delivered to customers.

3. Dredger description

Sand suction transporter is made up of sand suction transporter and small sand dredger. It can not only dredge sand in the river, but also can load sand to the river shore.

This dredger can unload sand into river and then the small shore sand suction dredger sucks sand into river shore, or it has a set of pump, so the sand will be discharged to river shore by the pump.

FAQ



1.Are you a  manufacturer ?

   Yes, we have our own factory.

 2.what kind of dredger should I choose?

   It depends on your  working environment , we will design the dredger according to  your need.

 3.Can you use an imported engine?

  Yes, we can, but the delievery time is much longer.

 4.Can I visit your factory?

   Yes, of course.  We  sincerely welcome you come and visit our factory if your time  permits.
