Specifications
sand suction machine1.Good after -service
2.Low cost
3.ISO9001
4.Delivery in time
sand dredger sand suction machine
1. Sand Suction Machine Feature
The dredger can be used to excavate and transport cohesive sediment. In the
course of technical designing, we have considered special requirements for tropical
climate conditions of Senegal such as meteorological and waters distributing state etc.
It is to be easy to dismantle or mount for transportation by road, rail or water,and is to
be easy to reassemble at project site
2. Sand Suction Machine Advantage
1)Economic and high sand dredging efficiency with can be with 30-50% denisty for
fine sand
2)Portable to move and can be transported by truck.
3)Easy to operate with reliable quality.5mm Steel plate thickness or followed to your request.
4)Standard world-wide available gearboxes and famous electric components.
5)Operation by one man from spacious and low noise operating cabin
6)Controls and instruments mounted in ergonomic dash board
7)Dredging depth can be 30m from the water surface.
3. Sand Suction Machine Parameter
Model | KDQSB200-5 |
Dredger Body |
|
Dimention (m) L*W*H | 12*4.7*1.2 |
Float |
|
Pontoon |
|
Side pontoons 2sets | 11*1.25*1.2 |
Main pontoon 1set | 8*2.25*1.2 |
Material | CCSA |
Total weight T | 20 |
Pump model | ZJQ300-20-37 |
Rotation speed(r/m) | 980 |
Dredging data |
|
Standard dredging depth | 5m |
Standard discharge distance | 50m |
Max.dredging depth(m) (optional) | 8m |
Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows) | 70m |
Max.standard dredging capacity m3/h | 50-70m3/h |
Min.clean water flows(standard dredging depth and Max.discharge distance) | 300m3/h |
Suction pipe diameter(mm) | 200mm |
Discharge pipe diameter(mm/inch) | 200mm |
The parameter is just for your reference,we can design as your requirement.
4. Sand Suction Machine Showing
Our dredgers working in the work site in different places of the world ,such as Bangladesh,
Southeast Asia,Africa, and so on.
5. Sand Suction Machine Simple Sketch
6. Sand Suction Machine Spare Parts
We also supply the whole set of spare parts for dredgers.
7. Submersible Sand Dredge Pump Boat Shiping Pictures
8. Submersible Sand Dredge Pump Boat Working Site
9. Submersible Sand Dredge Pump Boat Customers Visiting
10. Sand Suction Machine Boat Service
1)The seller must deliver the goods and spare parts with manuals written in English.
2.The seller will provide 12-months warranty for the quality of the diesel engine/generator,
motor water pump (impeller is 6months), storage battery, but not responsible for rust.
3) If need seller’s installation help, the seller will send one (1) qualified experienced
engineer and one translator to Africa to conduct installation and train 3 workers to
operate the machine, the buyer shall arrange at least 5-6 workers to help the engineer.
11.Company Information
1)Qingzhou Keda Mining Machine Co., Ltd.mainly produces iron selecting equipment,
kinds of drederes, dredging equipment, sand washing and sand making equipment,
gold panning equipment, magnetic separating, crusher and so on,
2)Products can produce according to the customers requirement and geographical condition.
3)It is a modern large-scale mineral processing equipment manufacturer for research and development,engineering design, producing installation, commissioning and after sale service.
4)Honesty and credit is our bussiness value , customer first.First-class quality and first-class
service is the business life
12.FAQ
In order to supply the best machine for you, could you tell me below information
ing capacity(t/h)?
2.Dredger dredging depth?
3.Any big stone in there?
13.Contact Person
Alice Li
Kede Mining Machinery Co.,ltd
Tel:0086-536-3880600
Mobile:0086-13793603966
Email:sales06 @miningmachine.net
Skype:kedamachinery06
Add:Qingzhou City,Shandong Province,China.
