Submersible Sand pump Dredger
Advantage
1)Economic and high sand dredging efficiency with can be with 30-50% denisty for
fine sand
2)Portable to move and can be transported by truck.
3)Easy to operate with reliable quality.5mm Steel plate thickness or followed to your request.
4)Standard world-wide available gearboxes and famous electric components.
5)Operation by one man from spacious and low noise operating cabin
6)Controls and instruments mounted in ergonomic dash board
7)Dredging depth can be 30m from the water surface.
Parameter
Model | KDQSB200-5 |
Dredger Body |
|
Dimention (m) L*W*H | 12*4.7*1.2 |
Float |
|
Pontoon |
|
Side pontoons 2sets | 11*1.25*1.2 |
Main pontoon 1set | 8*2.25*1.2 |
Material | CCSA |
Total weight T | 20 |
Pump model | ZJQ300-20-37 |
Rotation speed(r/m) | 980 |
Dredging data |
|
Standard dredging depth | 5m |
Standard discharge distance | 50m |
Max.dredging depth(m) (optional) | 8m |
Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows) | 70m |
Max.standard dredging capacity m3/h | 50-70m3/h |
Min.clean water flows(standard dredging depth and Max.discharge distance) | 300m3/h |
Suction pipe diameter(mm) | 200mm |
Discharge pipe diameter(mm/inch) | 200mm |
The parameter is just for your reference,we can design as your requirement.
1).1 year warranty main parts.
2).Profession technology provide installation,commissioning services.
3).24 hours technical support by e-mail or telephone.
1)Qingzhou Keda Mining Machine Co., Ltd.mainly produces iron selecting equipment,
kinds of drederes, dredging equipment, sand washing and sand making equipment,
gold panning equipment, magnetic separating, crusher and so on,
2)Products can produce according to the customers requirement and geographical condition.
3)It is a modern large-scale mineral processing equipment manufacturer for research and development,engineering design, producing installation, commissioning and after sale service.
4)Honesty and credit is our bussiness value , customer first.First-class quality and first-class
service is the business life
