multi-function wire drawing machine
- 5 Set / Sets per Month
- Shanghai or your port
- T/T
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Wanyi | Model Number: | LZ600 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
LZ10/600 Straight Line Drawing machine (Group) +furnace
1. Equipment comprising
(1) LZ10/600 straight line wire drawing machine (group)
(2) 450 trunk take-Up machine
(3) Man-machine interface control contact screen
(4) Whole set of electric console
2. Main technical parameter ( key points):
(1)Max. entering (steel) wire dia.6.5mm or 5.5mm
(2)Min. exiting (steel) wire dia.1.4mm(finished wire can be other diameter)
(3)Pulling steel wire material:low carbon steel wire
(4)Max.steel wire drawing speed:12m/s ( Normal using speed: 8m/s,but at same speed of take up machine )
(5)Water volume:10m3/h(Water pressure ≥0.25MPa)
(6)Air volume:3.5m3/h (Air pressure ≥0.6MPa)
(7)Motors: drawing unit:30X1KW+9X22KW AC freq. con. motor
Take-Up unit:11KW AC freq. con. motor
(
Specifications
1.ISO 9001:2008 standard certification
2.main foreign markets: mid-east,southeast Asia,south Asia,Africa,etc.
Detailed Sell Lead Description:
Description: LZ600 High speed straight wire drawing machine
Place Of Origin: Zhangjiagang City, Jiangsu, China
Company Published: 2009
Business type: Manufacturer
Number Of Employees: 50-100
Package: wooden case..
Feature: Applicable for drawing high, medium, low carbon steel wire/ alloy steel wire/ stainless steel wire,
with the feature of continuous pass drawing. The machine is controlled by PLC which is driven by frequency converter.
Specification:
Item | LZ200 | LZ300 | LZ400 | LZ500 | LZ560 | LZ600 | LZ700 | LZ750 | LZ900 | LZ1200 |
Dia. of Capstan | 200mm | 300mm | 400mm | 500mm | 560mm | 600mm | 700mm | 750mm | 900mm | 1200mm |
Capstan Nos. | 2~12 | 2~12 | 2~12 | 2~12 | 2~12 | 2~9 | 2~9 | 2~9 | 2~9 | 2~9 |
Inlet wire size | 2.5mm | 2.8mm | 4.2mm | 5.5mm | 6.5mm | 8mm | 10mm | 10mm | 14mm | 16mm |
Finished wire | 0.3mm | 0.6mm | 0.7mm | 1.2mm | 1.3mm | 1.6mm | 2.2mm | 2.2mm | 3mm | 3mm |
Max. Speed | 20m/s | 20m/s | 20m/s | 18m/s | 15m/s | 12m/s | 10m/s | 10m/s | 8m/s | 6m/s |
Power (Kw) | 5.5~7 | 7.5~11 | 7.5~22 | 22~45 | 22~55 | 45~75 | 45~90 | 55~90 | 90~132 | 90~160 |
