Silica Sand Spiral Ore Washing Machine

Silica Sand Spiral Ore Washing Machine photo-1
US$ 8,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Motor Type:
AC Motor
Power(W):
5-50 KW
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Motor Type AC Motor
Power(W) 5-50 KW
Capacity(t/h) 50
Place of Origin Henan, China
Brand Name Lanji
Model Number XL-610-XL1118
Dimension(L*W*H) 6.5*1.2*1.8M
Weight 2-30 T
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Silica sand Spiral ore washing machine  :

the XSL Series of silica sand  spiral Sand Washing Machine is suitable for washing and selecting, classifying, and trash-extracting in indusies, like metallurgy, construction, water and electricity, etc. this series of machine is suitable for washing and selecting materials of mid-fine and rough granularity.

Silica sand spiral ore washing machine

 Silica sand spiral ore washing machineSilica sand spiral ore washing machine

working principle of silica sand spiral ore washing machine  :

when the machine is working, the material goes into the input part. it will push the material to the output through the machine. surface dust and impurity are removed when the material from the input part to the output part is pushed, mixed and washed. the final product goes out through the discharge outlet and the mud and impurity will go out through overflow part.



Silica sand spiral ore washing machineSilica sand spiral ore washing machine



Spiral ore washing machine features:

1-high level cleaning and reasonable structure.

2-large capacity and small power consumption

3-small loss of sand during the process of sand washing.



spiral  ore washing machine /silica sand washing machine  technical parameters:

Model

Spiral diameter

(mm)

Feeding size

(mm)

(t/h)

Capacity

(t)

Power

(kw)

   Overall

Dimensions

  L*W*H (mm)

Weight(kg)

XL-508

508

≤10

14-88

 20

  5.5

8000X2343X1530

2670

XL-610

610

≤10

14-165

 50

  7.5

8000X2490X1530

3800

XL-762

762

≤10

18-124

 75

  11

9070X2650X1638

5225

XL-914

914

≤10

18-162

 100

  15

9070X2650X1638

6370

XL-1118

1118

≤10

27-333

 175

  30

9070X2830X1900

9800









Silica sand spiral ore washing machine

Silica sand spiral ore washing machine
