High efficiency spiral sand washing machine for concrete :
1. High cleaning;
2. Reasonable structure;
3. High capacity and low power consumption;
4. With the three functions of sand washing, grading and dehydration;
5.The spiral is driven by motor and decelerator to continuously rotate, and the sand or small ores can be stirred and washed.
XL Series Spiral Sand Washer can wash and separate the soil and foreign material in the sand. Its novel structure, adjustable overflow dam baffle and reliable arrangement can make sure the result of wash.
1. Spiral ore washing machine
Spiral classifiers are widely used for distributing ore in the close circuit with ball mill, grading ore and fine slit in the gravity mill, grading granularity in the flow of metal ore-dressing and desliming and dehydrating in the washing.
2. Spiral ore washing machine Application:
Spiral ore washing machine applied to metallurgy, building materials, water and electricity industries washing, grading, impurity,etc. This series apply to the fine-grained and coarse-grained materials washing operation.
3. Spiral ore washing machine working principle:
Spiral ore washing machine is mainly composed of the transmission device, the helicoid, tub, lifting mechanism and lower bearings(bearings) and mineral composition valve.
The material pours in from the end of input,the spiral impeller rotates by the driven of the motor and the reducer,and then push the material inside the hopper close to the end of output.Thus,under the action of being advanced,mixed and the flushing water,the mud wrapped on the material and the impurity go separately.Finally,the separated fine sands are discharged from the discharging port under the advancing movement of the spiral.Thus,the continuous work of washing sand is finished again and again.Promptly carries off the impurity and the small proportion foreign matters,and discharge from the overflow port tank washer,completes the cleaning action.The clean sand and crushed stone are carried off by the leaf blade,and finally poured into the discharge chute from the revolving impeller,completes the cleaning action.
Spiral sand washing machine structure:
Spiral sand washing machine/sand washer technical specifications:
| Model | XL508 | XL610 | XL762 | XL915 | 2XL915 | XL1115 | 2XL1115 |
| Screw Diameter (mm) | 508 | 610 | 762 | 915 | 915 | 1115 | 1115 |
| Length of Tub (mm) | 6705 | 7225 | 7620 | 7585 | 7585 | 9782 | 9782 |
| Max Feed Size (mm) |
≤ 10 |
≤ 10 |
≤ 10 |
≤ 10 |
≤ 10 |
≤ 10 |
≤ 10 |
| Capacity (t/h) | 20 | 40-50 | 50-75 | 100 | 200 | 175 | 350 |
| Speed of Screw (r/min) | 38 | 32 | 26 | 21 | 21 | 17 | 17 |
| Motor Power (kw) | 5.5 | 7.5 | 11 | 11 | 2*11 | 15 | 2*15 |
| Water Consumption(t/h) | 6~60 | 6~63 | 9~63 | 10~80 | 20~160 | 20~150 | 40~300 |
| Overall Dimensions(mm) | 8000* 2343* 1430 | 8000* 2050* 1400 | 8545* 2650* 3862 | 8500* 2810* 3600 | 8420* 3765* 3960 | 10970* 3945* 4720 | 10970* 5250* 4720 |
| Weight (t) | 2.67 | 3.80 | 5.23 | 6.27 | 11.11 | 10.18 | 17.94 |
1. Henan Lanji Machinery Manufacturing Co., Ltd is professional in producing large and medium-sized crushers, ball mills,mining equipments, brick/block making machine and so on.
2. Our clients spread all over the world. Products are sold to South Korea,, Indonesia, Vietnam,
Portugal, Africa and Middle East with the Annual export quantum composing one third of the total sales, wining praises from the purchasers.
Contact: Ms Sara
Mobile phone : 008613783471727
Skype: sarapang6
