Large capacity of Stone crusher machine (sand making machine ) with reasonable price

   Large capacity of Stone crusher machine (sand making machine ) with reasonable price    :

a small particle size,particle uniformity, large capacity, long life, power of small hammer,change three broken to two broken, process simplification, simple structure, convenient repair, stable running etc.

sand making machine  main model: PCX800*400,PCX800*600,PCX800*800,PCX1000*1000,PCX1200*1200,PCX1400*1400,etc. we will supply good quality and reasonable sand making machine price .

The impact fine crusher discharging grid plate adjusting size:5-20mm, the input size is  ≤120mm,the output size is below 5mm.the impact fine crusher is also called new type sand making machine,widly used for sand making plant.

sand making machine main structure:

The structure is  1. Lower case , Square steel, Grate bar assembly Grate bar , Hammer , Hammer block,Side plate,wheel boss,Second fine crushing chamber ,Hammer bolts,Top liner , Primary crushing chamber

Final products:

l

fine impact crusher/new type sand making machine working principle:

Working Principle :Stone less than 50mm enters sand making machine though conveyor belt. Stone is crushed by hitting other stones. Material falls down to impellor cavity. Under great centrifugal force, it hits material that coming downwards. After hitting each other, they force a vortex between impellor and shell, and hit each other several times, finally smaller stone comes out, and goes to vibrating screen. Satisfactory material is transported to sand washing machine, however overlarge material will go back to sand maker to be recrushed. Output sizes can be made according to customers requirement. If input size is larger than the designed size, other crushing equipment will be necessary.

fine impact crusher/sand making machine main technical data:

Fine impact crusher/new type sand making machine advantages:

This series feature of rational multi crushing chambers and novel double adjusting mechanism, which can ensure 85% of the discharged materials less than 3mm, and the uniformity of the product fineness can be controlled.

Easy access for maintenance has made the hammers and screen bars replaced much easier. All the wearing parts are made of new type of high chromium alloy materials with multiple elements so as to ensure the abrasive property and impact-resisting property of hammers and liner plates. This series of crushers also feature of stable operation, low dust and less power consumption which have prestigious advantages when comparing with conventional crushers.

Impact fine crusher installation site:

 Impact fine crusher delivery:
