Professional Processed Trommel Screen for Wood Chips Separation

Professional Processed Trommel Screen for Wood Chips Separation thumbnail-1
Professional Processed Trommel Screen for Wood Chips Separation thumbnail-2
Professional Processed Trommel Screen for Wood Chips Separation thumbnail-3
Professional Processed Trommel Screen for Wood Chips Separation thumbnail-4
Professional Processed Trommel Screen for Wood Chips Separation photo-1
Professional Processed Trommel Screen for Wood Chips Separation photo-2
Professional Processed Trommel Screen for Wood Chips Separation photo-3
Professional Processed Trommel Screen for Wood Chips Separation photo-4
US$ 1,500 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Circular, trommel screen for wood chips
Application:
Other, Ore, sand, coal ,lime
Contact Supplier Request Quote Chat Now
Henan Lanji Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Circular, trommel screen for wood chips
Application Other, Ore, sand, coal ,lime
Place of Origin Henan, China
Brand Name Lanji
Model Number GTS1040
Voltage 220/380/440V
Power(W) 3-20 KW
Dimension(L*W*H) 5.0*2.0*1.8 M
Weight 1-20 T
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Professional processed trommel screen for wood chips separation



Rotary screen Application:

Rolling screen is suitable to screen materials which are wet and easy blocking : sand gold ore, coal coke, lime ,etc. largest screened size is 100mm,middle size is 10-50mm,  fine size is below 3mm



Professional processed trommel screen for wood chips separation

Rotary screen working principle:

Rolling screen is composed by the rolling drum, funnel, gear box, motor .The materials enter the rolling drum, one hand, the materials are screened by the drum rolling, another hand ,the large size materials flow ahead with the rolling drum gradient, and then sorted out through different screen net size. The screen size fall in the funnel accordingly.

Professional processed trommel screen for wood chips separation

Rotary screen feature:

1. Long bearing lifetime

2. High efficiency and low energy consumption

3. High credits and good quality

4. Not easy to be blocked.

Technical data:

Model

Specification

(m)

Slope

Rotary speed

Sieve pore(mm)

Max feeding size (mm)

Production capacity(m3/h)

Motor power

(kw)

Sieve pore(2mm)

Sieve pore(20mm)

GTS820

Φ0.8X2

6°

32

2-20

Mesh size X2.5

7

30

3

GTS830

Φ0.8X3

6°

32

2-20

Mesh size X2.5

8

50

3

GTS1030

Φ1X3

6°

25

2-20

Mesh size X2.5

10

60

4

GTS1040

Φ1X4

6°

25

2-20

Mesh size X2.5

11

80

4

GTS1230

Φ1.2X3

6°

20

2-20

Mesh size X2.5

12

100

5.5

GTS1240

Φ1.2X4

6°

20

2-20

Mesh size X2.5

14

120

5.5

GTS1250

Φ1.2X5

6°

20

2-20

Mesh size X2.5

15

140

5.5

GTS1530

Φ1.5X3

6°

17

2-20

Mesh size X2.5

16

120

5.5

GTS1540

Φ1.5X4

6°

17

2-20

Mesh size X2.5

18

150

7.5

GTS1550

Φ1.5X5

6°

17

2-20

Mesh size X2.5

20

180

11

GTS1560

Φ1.5X5

6°

17

2-20

Mesh size X2.5

22

200

11

 Professional processed trommel screen for wood chips separationProfessional processed trommel screen for wood chips separation
