Wet mill machine for gold mining Introduction:
The wet wheel mill is also called wet gold ore grinding machine. It is praised by users because of it has the features of low investment, high production capacity, low consumption, good efficiency, easy installation and maintenance. It is the excellent equipment which can instead of ball mill. It is perfect equipment for medium-sized and small enterprises. The roll gold machine is mainly used for separate gold, silver, lead, zinc, iron, molybdenum, cooper, antinomy and so on.
Working principle of Wet mill machine for gold mining :
1.Firstly the motor will transmit the motive power to reduction gears,under the drive of reduction gears it
passing through large vertical spindle,then the power cabient transfers to above whippletree.
2.The whiffletree pulls the two runner wheels rotation,runner wheels not only revoluting around
the large vertical spindle but also could retating by themselves.
3.After adding into grinding materials, the materials are under the extrusion of grinding roller weight to revoluting and rotating
with runner wheels,when twisting form huge friction force with grinding base. And after suffering
repeated extrusion, the materials can be crushed thoroughly.
Wet mill machine for gold mining Main Technical Parameter:
Model |
1200 |
1100 |
1000 |
900 |
850 |
Roller Diameter(mm) |
1200+ 10 |
1100+10 |
1000+10 |
900+10 |
850+10 |
Pan Diameter (mm) |
1800+20 |
1800+20 |
1800+20 |
1700+20 |
1700+20 |
Pan Diameter Slot Width (mm) |
1500 |
1400 |
1300 |
1200 |
1100 |
Pan Thickness(mm) |
100-80 |
100-80 |
100-80 |
60-45 |
60-45 |
Roller Speed(rpm) |
For gold 10-13 others 18-22 |
10-13 |
10-13 |
||
Daily Capacity(tpd) |
Gold 10 |
Gold 8 |
Gold 5 |
Gold 3 |
Gold 2 |
Power(kw) |
7.5 |
5.5 |
5.5 |
3 |
3 |
Input Size(mm) |
<25mm |
||||
Wet mill machine for gold mining structure:
