US$ 8,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Ball Mill, small ball mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Henan Lanji Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Ball Mill, small ball mill
Motor Type AC Motor
Power(W) 18.5-1250
Capacity(t/h) 0.65-2
Place of Origin Henan, China
Brand Name Lanji
Model Number 900*1800
Dimension(L*W*H) 5.0*2.0*2.1 m
Weight 3.6 t
Certification ISO9001:2000
Warranty 1 year including wearing parts
After-sales Service Provided Engineers available to service machinery overseas

Energy saving limestone dry  ball mill :



Limestone ball mill :

1.simple structure ball mill

uced consumption by 30%

3.increased capacity by 20%

4.Improve fineness



Energy saving limestone dry ball millEnergy saving limestone dry ball mill

Limestone ball mill features:

1)New type on improved on the old type 2) Large diameter double roe self-aligning roller bearings



3) The whole rack, easy to install 4) By adopting an integral steel under-frame,installation precision is high.

Limestone ball mill working principle:

ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Energy saving limestone dry ball mill

Limestone ball mill main technical parameters:



Model Cylinder rotary speed(r/min)  Loading ball weight(t) Input size(mm) Discharge size(mm) Capacity(t/h) Motor power (kw) Weight (t)
Ø900×1800 39 1.5 ≤20 0.075-0.89 0.8-2 18.5 4.6
Ø900×3000 39 2.7 ≤20 0.075-0.89 1~4 22 5.6
Ø1200×4500 32 5 ≤25 0.074-0.4 1.6-5.8 55 13.8
Ø1500×3000 27 7.5 ≤25 0.074-0.4 2~5 75 15.6
Ø1500×5700 28 12 ≤25 0.074-0.4 3.5-6 130 24.7
Ø1830×3000 25 11 ≤25 0.074-0.4 4~10 130 28
Ø1830×6400 24 21 ≤25 0.074-0.4 7~16 210 34
Ø2100×3600 23 19 ≤25 0.074-0.4 10-36 210 46
Ø2200×4500 21 27 ≤25 0.074-0.4 12~23 280 48.5
Ø2200×6500 21 35 ≤25 0.074-0.4 14-26 380 52.8
Ø2200×7000 21 35 ≤25 0.074-0.4 15-28 380 54
Ø2200×7500 21 35 ≤25 0.074-0.4 15-30 380 56
Ø2400×4500 21 30 ≤25 0.074-0.4 18-45 320 65
Ø2700×3600 21 39 ≤25 0.074-0.4 19-75 400 83
Ø2700×4500 20 48 ≤25 0.074-0.4 22-85 430 89
Ø3200×4500 18 65 ≤25 0.074-0.4 29-140 800 137
Ø3200×5400 18 81.6 ≤25 0.074-0.4 30-180 800-1000 146
Ø3600×4500 17 88 ≤25 0.074-0.4 35-210 1000 190
Ø3600×8500 17 144 ≤25 0.074-0.4 45-260 1800 260

 Energy saving limestone dry ball millEnergy saving limestone dry ball mill





 Energy saving limestone dry ball mill

Energy saving limestone dry ball mill
