Secondary fine jaw crusher for concrete crushing :
There are two main types of concrete jaw crushers - single toggle and double toggle.
Jaw crusher Description:
Concrete Jaw crusher is made up by the dynamic and static jaw plates composed of two crushing chamber to simulate the movement of animals to complete two jaw crusher crushing materials, special equipment for gravel.
A Jaw Crusher is one of the main types of primary crushers in a mine or ore processing plant. The size of a jaw crusher is designated by the rectangular or square opening at the top of the jaws (feed opening). For instance, a 24 x 36 jaw crusher has a opening of 24" by 36", a 56 x 56 jaw crusher has a opening of 56" square. Primary jaw crushers are typically of the square opening design, and secondary jaw crushers are of the rectangular opening design
Jaw crusher structure drawing:
Concrete jaw crusher working principle:
A Jaw Crusher reduces large size rocks or ore by placing the rock into compression. A fixed jaw, mounted in a "V" alignment is the stationary breaking surface, while the movable jaw exerts force on the rock by forcing it against the stationary plate. The space at the bottom of the "V" aligned jaw plates is the crusher product size gap, or the size of the crushed product from the jaw crusher. The rock remains in the jaws until it is small enough to pass through the gap at the bottom of the jaws.
Concrete jaw crusher parts:
Technical data of jaw crusher:
Model |
Feed opening size |
Max Feed |
Adjusting |
Capacity |
Rotation speed of eccentric shaft |
Motor power |
Total weight |
Dimensions |
PE-150×250 |
150×250 |
125 |
10-40 |
1-3 |
250 |
5.5 |
0.8 |
720×660×850 |
PE-200×300 |
200×300 |
180 |
15-50 |
2-6 |
260 |
7.5 |
1.2 |
910×750×990 |
PE-200×350 |
200×350 |
180 |
18-70 |
3-10 |
260 |
11 |
1.5 |
1000×870×990 |
PE-250×400 |
250×400 |
210 |
20-60 |
5-20 |
300 |
15 |
2.8 |
1300×1090×1270 |
PE-400×600 |
400×600 |
340 |
40-100 |
16-60 |
275 |
30 |
7 |
1730×1730×1630 |
PE-500×750 |
500×750 |
425 |
50-100 |
40-110 |
275 |
55 |
12 |
1980×2080×1870 |
PE-600×750 |
600×750 |
500 |
150-200 |
80-240 |
275 |
55 |
15.8 |
2070×2000×1920 |
PE-600×900II |
600×900 |
500 |
65-160 |
50-180 |
250 |
55 |
17 |
2190×2206×2300 |
PE-750×1060 |
750×1060 |
630 |
80-140 |
110-320 |
250 |
110 |
29 |
2660×2430×2800 |
PE-800×1060 |
800×1060 |
640 |
130-190 |
130-330 |
250 |
110 |
29.8 |
2710×2430×2800 |
PE-830×1060 |
830×1060 |
650 |
160-220 |
150-336 |
250 |
110 |
30.7 |
2740×2430×2800 |
PE-870×1060 |
870×1060 |
660 |
200-260 |
190-336 |
250 |
110 |
31.5 |
2810×2430×2800 |
PE-900×1060 |
900×1060 |
685 |
230-290 |
230-390 |
250 |
110 |
33 |
2870×2420×2940 |
PE-900×1200 |
900×1200 |
750 |
95-165 |
220-450 |
200 |
110 |
52 |
3380×2870×3330 |
PE-1000×1200 |
1000×1200 |
850 |
195-265 |
315-500 |
200 |
110 |
55 |
3480×2876×3330 |
PE-1200×1500 |
1200×1500 |
1020 |
150-350 |
400-800 |
180 |
160 |
100.9 |
4200×3300×3500 |
PE-1500×1800 |
1500×1800 |
1200 |
220-350 |
500-1000 |
180 |
280 |
122 |
5160×3660×4248 |
PE-1800×2100 |
1800×2100 |
1500 |
300-400 |
600-1200 |
160 |
400 |
150.6 |
6210×4013×4716 |
PEX-150×750 |
150×750 |
120 |
18-48 |
8-25 |
320 |
15 |
3.8 |
1200×1530×1060 |
PEX-250×750 |
250×750 |
210 |
25-60 |
13-35 |
330 |
30 |
5.5 |
1380×1750×1540 |
PEX-250×1000 |
250×1000 |
210 |
25-60 |
16-52 |
330 |
30 |
7 |
1560×1950×1390 |
PEX-250×1200 |
250×1200 |
210 |
25-60 |
20-61 |
330 |
37 |
9.7 |
2140×1660×1500 |
PEX-300×1300 |
300×1300 |
250 |
20-90 |
16-105 |
300 |
55 |
15.6 |
2720×1950×1600 |
Servie:
1.Installation: The seller provide all drawings for installation, engineers available to service machinery overseas.
2.After sale service: 1year guarantee.
