Product Details

Place of Origin	Zhejiang, China		Brand Name	ICOM
Model Number	ZQZ5161GLQ		After-sales Service Provided	Engineers available to service machinery overseas

ASPHALT DISTRIBUTOR

Intelligent Asphalt Distributor is an intelligent high-tech product which can spread emulsified asphalt,

fluxed asphalt,

oil refining asphalt, heated asphalt,

heavy traffic paving asphalt and high viscosity modified asphalt.

The product has been widely used in highway construction and road maintenance projects.

It can be used for construction of upper and lowers seal coat, prime coat, waterproof layer,

bonding layer,

bituminous surface treatment,

bituminous penetration pavement,

fog seal and other projects of different grades of highway pavement.

It can also be used for transportation of liquid asphalt or other heavy oil.

Mass parameter:
Kerb Weight(kg)	8900	Total Weight(kg)	16000
Rated loading Weight(kg)	7100	Dimension(mm)	8995×2490 ×3160
Chassis Parameter:
Chassis Model	DFL1160BX7A	Tyre model	9.00-20,9.00R20
Wheelbase (mm)	5000	Tread mm	1815/1800
Front Overhang(mm)	1430	Rear Overhang(mm)	2565
Approach angle,Departure angle	20°/11.3°	Minimum Ground Clearance (mm)	250
Engine parameter:
Engine model	EQH160-30	Manufacturer	DongFeng Motor Co., LTD
Max.Power(kw)	118/2400	Max. Torque(N.m)	550/1300-1800
Fuel	Diesel	Displacement(ml)	4752
Spray specification:
Tank Capacity(m³)	8	Spray width	6000mm
Hydraulic pump model	CBQ-F550	Spray Value	0.5-3.0(Kg)
Hydraulic motor	L2F63W2P2 (Liyuan)	Insulation Thickness	50mm
Controller	/	Nozzles	39
Burner	G20(Riello)	Asphalt pump	CB450
Generator(Converter)	YGBT2500

Mass parameter:
Kerb Weight(kg)	9750	Total Weight(kg)	16000
Rated loading Weight(kg)	6055	Dimension(mm)	8998×2490 ×3200
Chassis Parameter:
Chassis Model	DFL1160BX	Tyre model	9.00-20,9.00R20
Wheelbase (mm)	5000	Tread mm	1815/1800
Front Overhang(mm)	1430	Rear Overhang(mm)	2568
Approach angle,Departure angle	20°/14°	Minimum Ground Clearance (mm)	250
Engine parameter:
Engine model	B190 33	Manufacturer	Dongfeng Cummins Engine Co. , Ltd.
Max. Power(kw)	140/2400	Max. Torque(N.m)	550/1300-1800
Fuel	Diesel	Displacement(ml)	5900
Spray specification:
Tank Capacity(m³)	8	Spray width	6000mm
Hydraulic pump model	CBQ-F540	Spray Value	0.5-3.0(Kg)
Hydraulic motor	L2F63W2P2 (Liyuan)	Insulation Thickness	50mm
Controller	ZM-Ⅰ	Nozzles	39
Burner	G20(Riello)	Asphalt pump	QGB450
Generator(Converter)	EC6500CX
