Vertical wind turbine/wind generator/VAWT/Maglev permanent wind turbine/windmill generator power system
Overview:
BF series wind power generating set utilize a new aerofoil vertical axis wind wheel and magnetic suspention structure, choose high strength glass fibre reinforced plastic and epoxy resin to make blades. This series VAWT have earned many items of national patent, in the leading position. BF series VAWT are widely used in the areas where are good environments for wind energy. It can offer the uninterrupted power supply(UPS) for electrical equipments in areas,where are no electricity.It is suitable for off-grid system and on-grid system.
Vertical wind turbine generator(VAWTs)are a type of wind turbine where the main rotor shaft is set vertically and the main components are located at the base of the turbine. VAWTs offer a number of advantages over traditional horizontal-axis wind turbines (HAWTs). They can be packed closer together in wind farms, allowing more in a given space. they are smaller, but rather due to the slowing effect on the air that HAWTs have, forcing designers to separate them by ten times their width.
BF Maglev vertical wind turbine/wind generator is quiet,light, Omni-directional, and they do not create as much stress on the support structure. They do not require as much wind to generate power, thus allowing them to be closer to the ground. By being closer to the ground they are easily maintained and can be installed on chimneys and similar tall structures.
Vertical wind turbine/wind generator/VAWT/Maglev permanent wind turbine/windmill generator power system---suggested for:
· Household,Garden,farm eolic vertical wind turbine generator,Off grid and on grid power system
· Telecom sites.
· Rural electrification programs. Island , sentry, island, sight lighting
· Make wind -solar hybrid power system
Vertical wind turbine/wind generator/VAWT/Maglev permanent wind turbine/windmill generator power system
Characteristic:
1.utilize a new aerofoil vertical axis wind wheel and magnetic suspention structure
2.the start-up wind speed is very low
3.the wind energy coefficient is very high
4.the anti-wind capability is high
5.the weight of generator is very light
6.operation is stable
7.have no noise
8.with careful anti-corrosion treatment and good sealing
9.maintenace free
10.long service life
Main Products:
Maglev 3KW/5KW/10KW vertical wind turbine /wind power generator/permanent magnetic windmill generator power off/on grid system
Power(w) | 300 | Rated wind speed | 11 |
Rotor diameter | 1.2 | Start-up wind speed | 1.6 |
Height of blade | 1.4 | Range of working wind speed(m/s) | 1.8-25 |
Material of blades and numbers | Glass Fiber Reinforced Plastic/5 | Survival wind speed | 40 |
Rated rotor speed | 200r/min | Output Voltage | AC12/24V |
Speed regulation method | Electromagnetic control | Stop method | Electromagnetic brake |
Wind energy utilized coeffeicent | 30%-40% | Sweep wind area | 1.68 |
Range of working temperature | -45℃-60℃ | Suggested supporting battery | 2pcs12v100ah |
Top weight (kg) | 70 | Tower type and height | Guy cable tower/6-8m |
