10kw Wind Power Generator

Specifications

1.10kw wind power generator
2.low start up wind speed
3.high wind energy efficient.
4.CE,ISO certified.
5.10kw wind power

10kw wind power generator





1.The warranties for our wind turbines is 2 years.
2.Our product passed CE,ISO certification,the generator assembly is high reliability,high efficiency,light weight,good surface and sealing.

3.Besides,our BF-H series wind power generating set utilize a new aerofoil vertical axis wind wheel and magnetic suspention structure,the wind energy cofficient is very high,the start-up wind speed is very low,the anti-wind capability is high.have no noise.

4.What's more,the wind turbine's tower our engineer designed is free standing tower for security, as the generator and blades are much more big and heavy,so the price is a little bit high.

5.Generally speaking,our wind turbine is very fair in configuration,superior in quality,high in security.and the warranties for our wind turbines is 2 years. you can use it enduringly and safely.



Techinical parameters:

Model:BF-H-10KW

Generator Type: permanent magnetic direct drive VTAW, 3 phase AC

Power(w)	10000	Rated wind speed (m/s)	12
Rotor diameter (m)	6	Start-up wind speed (m/s)	3.8
Height of blade (m)	6.6	Range of working wind speed(m/s)	3.8-25
Material of blades and numbers	Glass Fiber Reinforced Plastic/5	Survival wind speed (m/s)	50
Rated rotor speed (m/s)	100r/min	Output Voltage	AC380/600V
Speed regulation method	Electromagnetic control	Stop method	Electromagnetic brake
Wind energy utilized   coeffeicent	30%-40%	Sweep wind area	28.26
Range of working temperature	-45°C-60°C	Suggested supporting battery	32pcs12v200ah
Top weight (kg)	660	Tower type and height	Free standing tower/10m
