Specifications
1.5kw vertical axis wind generator2.low start up wind speed
3.high wind energy efficient
4.CE,ISO certified
5.maintenance
5kw vertical axis wind generator
BF/VAWTH series wind power generating set utilize a new aerofoil vertical axis wind wheel and magnetic suspention structure,the wind energy coefficient is very high, the start-up wind speed is very low,the anti-wind capability is high,have no noise.
Power(w) |
5000 |
Rated wind speed (m/s) |
11 |
|
Rotor diameter (m) |
4 |
Start-up wind speed (m/s) |
3.2 |
|
Height of blade (m) |
3.7 |
Range of working wind speed(m/s) |
3.2-25 |
Material of blades and numbers |
Glass Fiber Reinforced Plastic/5 |
Survival wind speed (m/s) |
50 |
|
Rated rotor speed (m/s) |
150r/min |
Output Voltage |
AC220/380V |
Speed regulation method |
Electromagnetic control |
Stop method |
Electromagnetic brake |
Wind energy utilized coeffeicent |
30%-40% |
Sweep wind area |
12.56 |
Range of working temperature |
-45°C-60°C |
Suggested supporting battery |
18pcs12v120ah |
Top weight (kg) |
485 |
Tower type and height |
Free standing tower/8m |
