5 R griding mill for limestone / Gypsum / Dolomite and Etc.
- 100 Set / Sets per Month
- Guangzhou/ Shenzhen
- T/T
Product Details
Condition: | New | Type: | Raymond Mill | Motor Type: | AC Motor |
Power(W): | 392 kw | Capacity(t/h): | Depends | Place of Origin: | Guangxi, China |
Brand Name: | HCM | Model Number: | HCH1000 | Dimension(L*W*H): | 16.5*9.3*10.3 M |
Weight: | 17.8-50t | Certification: | ISO9001:2008/CE/BV | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
5 R griding mill for limestone / Gypsum / Dolomite and Etc.
Product Description
Product Application
The HC ultrafine grinding mill is a new ultrafine pulverizing equipment designed by HCM.It is widely used to grind any non-metallic minerals with Mohs hardness below 7 and moisture below 6%,such as limestone, talc, calcite carbonate, dolomite,bentonite, kaolin, graphite, barbon black etc.. This kind of the mill especially suitable for ultrafine grinding.The fineness can be adjusted from 0.045mm (325 mesh) to 0.005mm (2500 mesh), which is wider than traditional Raymond mill.
Limestone Calcite Dolomite
Technical Advantages and Feature
1. Reliable Performance
Higher production capacity and lower consumption: Non metallic mineral particles feed which feeding sizes is less than 10mm, can be one-time processed as< 10m powder (97% passing).The particle size less than 3 um accounted for about 40%, which contributes to a large specific surface area.It has the advantages of low cost, high efficiency, and good product fineness.
2. Forced Turbine Classifying System (patent No. ZL201030143470.6)
The fineness can be adjusted flexibly from 0.04 mm(400 mesh) to 0.005 mm(2500 mesh).Products with various fineness can meet the market needs and improve your competitiveness.
3. Full Paulse Collecting System (Patent No.CN200920140944.3)
The pulse collection system will remove 99.9% of the dust,ensuring dust-free operation environment. The pulse dust collection system is HCM special invent comply for the environment protection requirements. The pulse dust collection system is adopted with pulse-jet type of cleaning. By utilize the compression air to shoot clean each filtering bag. High and complete dust cleaning. Prevent bags from powder stocking.
4. Lower Wear-resistance Rate
The wearing parts (roller and ring) made from special wear-resistant material which prolongs working life.
5.Absorb Vibration and compact structure
The mill base is inblock casting, which ensure the structural strength and alleviates vibration.
Product Structure
HC1000 Main Machine
SUPPORT & SERVICE
Professional pre-sales and after-sales services ensure the high quality grinding mill running more smoothly and efficiently. Hongcheng has a professional, high efficiency and stable sales and service team and extensive sales and service network, which can provide our customers the most enthusiasm service and strong technical support worldwide.
Pre-sales Service:
1. Assistance in mill model selection
2. Guidance on workshop layout and site selection
3. Engineers to be at your place for free to do on-spot design and flow chart.
Mid-sales Services:
1. Perfect quality control system and strict inspection before delivery.
2. Assistance in providing logistics and on-time delivery.
After-sales Services
Free guidance on foundation-making
Free guidance on installation and testing
Free training in repair and maintenance
Professional after-sales team with 21 after-sales service offices in China and abroad, and 24*7 hours work per week.
Service Line: +86-138-2449-7223
Spare Parts
Amply supply of spare parts to meet customers’immediate needs.
CUSTOMERS’ SITE
