Raymond Mill/Grinding Mill/Ultrafine Mill---China No.1 +3000 Case Plants in China
Application of Talc Grinding Mill :
Also choice for nonflammable and non-explosive minerals of which Moh’s hardness is less than 9.3, moisture content is less than 6%, for example: quartz, feldspar, calcite, talcum, barite, fluorite, Rare earth, marble, ceramic, aluminous bauxite, manganese ore, iron ore, copper ore, phosphorus rock, red ferric oxide, Zircon, slag, granulating slag, cement clinker, active carbon, dolomite, granite, garnet, yellow ferric oxide, fertilizer, multiplex fertilizer, fly ash, soft coal, coking coal, lignite, magnesite, chromium oxide green, gold ore, red clay, clay, kaolin, coal tar creosote, coal slack, porcelain clay, cyanite, fluorspar, bentonite clay, medical stone, rhyolite, greenstone pyrophillite, shale, basalt, gypsum, graphite.
Working Principles of Talc Grinding Mill :
Firstly, raw material is crushed by jaw crusher to the required size, which is lifted up to the hopper. Secondly, the raw material goes into the grinding chamber through the electro-magnetic vibrating feeder at an even rate. Thirdly, the raw material lifted by the shovel is ground into powder between the ring and roller. Fourthly, the powder is blown up to the cyclone collector through the classifier, which will be collected through the discharging valve. The unneeded powder, which cannot go through the classifier, will be reground into the needed powder.
Advantages of HC1700 Talc Grinding Mill :
1) The only professional producer of Raymond Mill in China.
2) Powder-saving and Higher Production Capacity (1-40T/H)
3) Smooth and Reliable Performance.
4) Fineness: 100—600 Mesh (Adjustable)
5) Run for 1000 hours without Lubrication
Technical Data of Talc Grinding Mill :
Model |
HC1000 |
HC1300 |
HC1460 |
HC1700 |
HC2000 |
|
|
Roller |
Number of Rollers |
3 |
4 |
4 |
5 |
5 |
Diameter(mm) |
320 |
410 |
460 |
510 |
620 |
|
Height(mm) |
200 |
230 |
250 |
250 |
250 |
|
Ring |
Inner Diameter(mm) |
970 |
1270 |
1460 |
1700 |
2000 |
Height(mm) |
200 |
210 |
250 |
250 |
250 |
|
Max. Feeding Size(mm) |
≤20 |
≤25 |
≤35 |
≤50 |
≤50 |
|
Fineness(mm) |
0.022-0.18 |
0.022-0.18 |
0.022-0.18 |
0.022-0.18 |
0.022-0.18 |
|
Total Power(kw) |
105 |
183.5/198.5 |
242 |
364 |
670 |
|
Capacity(t/h) |
1.5-6 |
3-12 |
5-15 |
6-25 |
20-45 |
|
Weight(t) |
14 |
28 |
37 |
46 |
132 |
|
