Jinan Datong snacks food making machine production line
1. Snacks making machine Description:
Snacks machine can produce breakfast cereal which is one kind of nutritional convenient food which is produced by this process line, using grist as basic material, with different shapes, such as, granule, flake, animal, etc. One outstanding characteristic of the breakfast cereal is that it contains abundant compound carbohydrates and dietary fibre, strengthens lots of microelements, such as vitamin and mineral, and also can be added with cocoa and sugar, like honey and maltose. It can be drunk directly after mixed into coffee, milk, yoghourt or functional drink. Children can eat breakfast cereal as sweet crispy snack.
2. Raw materials: adopts corn flour as raw material
3. Products:This line can be used to produce corn flakes, breakfast cereals, different kinds of snacks by adjusting the moulds from extrude
4. Capacity: 150kg/h, 300kg/h
5. Flow chart:Mixing system---Extrusion system---Flaking system---Drying system---Sugar Spraying system ---Drying system---- Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
7. Machines Materials:All the machines are made by stainless steel
8. Technical Parameters:
Mixer
1.Main motor :4.0Kw
2.Size:1.2*0.9*1.4m
3.Output:30kg-4.0kg/time
Functions:
Mixer makes the raw material which adding water and liquid chemical additive fully mixer equally.the machine mixes the flour and prepares them ready to be used in the next step.
Name: screw conveyor
Brand: Datong
Original: China
It is used to convey the mixed raw materials to the feeder of the extruder.There is no leaking,dusting and pollution during the conveying.
Name: Extruder
Brand: Datong
Original: China
we can supply your different models extruder according to your targer capacity.With a same extruder,you can produce different shapes of food by changing different moulds.
Name: Hoister
Brand: Datong
Original: China
Food types PVC for material touch place.
Main Motor:1.2kw
Size:2.0x0.5x2.8 (m)
Convey the product from dryer to double roller.
Name: Dryer
Brand: Datong
Original: China
It is used for drying.The net belt running speed can be controlled to change the food drying time in the dryer.The temperature also can be controlled.
Flavouring System
Output:100-1000kg/h
Size:3.9*0.7*1.3m
Main power:1.5kw
1.The inside turning container is very sanitary because of adopting the stainless steel material.The small roller is used for the small output whereas the big roller is used for the plentiful output.
2.We can spray the oil and sprinkle flavoring material in this .First drum,we can flavoring products automatically.This drum is easy to operate it and easy to clean it after day work.
1. Free consultation service before, during, and after sales;
2. Free Project planning and design services upon clients' special demands;
3. Debugging and inspecting of equipment until everything is functional before leaving the factory;
4. Overseas installation and training of equipment maintenance and operating personally;
5. Provide basic production techniques and formulas;
6. 1 year complete warranty for Extruded Food Wheat Corn Snacks Making Machine
