Help CenterZ145WB Jolt Squeezer
Related Products
-
Z145WA Jolt SqueezerUS$ 3,200 - 3,450MOQ: 1 Set -
Foundry Use Sand Moulding Machine From ChinaUS$ 55,000 - 60,000MOQ: 1 Set
-
Microseism Jolt Squeeze Clay Sand Molding MachineUS$ 2,600 - 5,000MOQ: 1 Set
-
China Jolt Squeeze Metal Molding MachineUS$ 2,600 - 5,000MOQ: 1 Set
-
Automatic Flaskless Shoot Squeeze Molding MachineUS$ 55,000 - 60,000MOQ: 1 Set
features
1.The machine using the fuselage box structure basket to improve the body of the steel.
2.It adopt microseism squeeze molding technics used to significantly increase the pressure and the strength to make up hardness HB85 sand box more than one level to increase surface roughness, make the quality of the other products stable.
3.Shock part of it with a buffer spring, effectively reduce the impact of machine-to-base.
4.The machine adopt cylinder, crank, connecting rod, synchronizing shaft achieve molding synchronously.
5.Control part, all pneumatic components used to achieve the overall functionality, simple operation, easy maintenance.
6.It is easy to operate, visual sand, the operational procedures can be humane and effective to increase productivity.
ITEM | UNIT | Z143W | Z144W | Z145W | Z146W | Z146WB | Z148CW | Z148E |
Flask dimension | mm | 400*400*100 | 400*500*180 | 450*500*200 | 500*600*200 | 500*600*200 | 630*800*320 | 900*800*320 |
Worktable dimension | mm | 560*420 | 465*500 | 600*460 | 550*700 | 550*700 | 900*730 | 1000*820 |
Air pressure | Mpa | 0.55 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Compressive stress | kgf | 4000 | 4200 | 6300 | 7000 | 8300 | 12000 | 18000 |
Compress process | mm | 100 | 120 | 160 | 160 | 160 | 180 | 200 |
Drawing mould process | mm | 160 | 150 | 200 | 200 | 200 | 320 | 320 |
Distance compacting plate with worktable | mm | 200-370 | 300-400 | 300-450 | 350-450 | 450-600 | 680 | 600-700 |
Productivity | mould/h | 40-60 | 40-60 | 40-60 | 40-60 | 40-60 | 40-60 | 40-60 |
Out line dimension L*W*H | mm | 950*680*1280 | 1050*1100*1410 | 1200*1000*1693 | 1380*850*1565 | 800*1200*1670 | 1600*1038*2200 | 1152*1162*2292 |
Advantage structure:
the flask lifting structure is adopt new designing, piston is movable , instead of cylinder sleeve moving , so this new structure only need piston seal, not need two seal parts.
It is prolong the service time twice as other machine.
Famous brand pneumatic element
