Help Center70-150 Kg/hour Capacity Wood Sawdust Pellet Machine/poulry Pellets Making Mills With Low Investment
Related Products
-
1-1.5 T/h High Efficiency Wood Pellet Mill/Wood Pellet Machine With CE CertificationUS$ 22,000 - 22,000MOQ: 1 Set -
Low Energy Consumption Flat Die Wood Pellet Machine/biomass Pellets Mill for SaleUS$ 800 - 800MOQ: 1 Set
-
Parts Feer Bio Wood Pellet Mill/feed Pellets Machine With Good PriceUS$ 800 - 800MOQ: 1 Set
-
High Capacity Ring Die Biomass Wood Pellet Machine/ Wood Pellet Mill/poultry Feed Pellet Machine With Good QualityUS$ 1,000 - 1,000MOQ: 1 Set
-
High Quality 100~3000 Kg/h Wood Pellet Making Machine/ Wood Pellet Machine Professional ManufacturerUS$ 1,000 - 1,000MOQ: 1 Set
Highlight of Wood Pellet Machine
1,Pellet making machine can process the corn husk, rice husk,sugar cane rods,straw,sawdust,bamboo powder,peanuts shell,cotton seed shell,etc.make agriculture waste into wood pellet or feed pellet.
2,Users can change motor and die to meet different yield demands.The production capacity range is 40-600 kg wood pellet and feed pellet per shift every year.
3,Vertical feeding directly in place.
4,Low investment for customers,less floor space occupation, compact structure,and easy operation and mobile,easy assembly and disassembly,shipped and installed.
5,With excellent quality die and rollers.
Raw Material Condition For Wood Pellet Machine
1,The maximum size of the materials are not more than the diameter of the pelletizing hole. i.e, if the diameter of the hole is 6mm, the length of the saw dust cannot be more than 6mm. Please ensure the proper size of raw material according to the diameter of the hole.
2,Different raw materials have different moisture content requirement.
3,The moisture content of sawdust for the die-driving Pellet Mill is specified to 10%-18%. and roller-driving Pellet Mill is 10%-14%. The materials should be mixed evenly.
4,This machine can process one kind material and evenly mixture, small pieces of hard goods can’t
be mixed, otherwise the machine die and roller will be damaged.
The technology parameters of small bio wood pellet machine:
APPEARANCE | DRIVEN BY | MODEL | POWER | CAPACITY (kg/h) | WEIGHT (nw/gw) | PACKING SIZE (mm) |
| Electric motor | ZLSP-D 150B | 5.5kW | 50-100 | 95/110 | 800x450x700 |
ZLSP-D 200B | 7.5 kW | 80-120 | 200/230 | 1050x480x930 | ||
ZLSP-D 230B | 11 kW | 120-200 | 290/320 | 1180x540x1000 | ||
ZLSP-D 260B | 15 kW | 160-250 | 320/360 | 1240x540x950 | ||
ZLSP-D 300B | 22 kW | 250-400 | 350/380 | 1300x560x1100 | ||
| Electric motor | ZLSP-D 150C | 5.5kW | 60-110 | 105/125 | 1000x480x780 |
ZLSP-D 200C | 7.5 kW | 80-120 | 210x230 | 1050x550x830 | ||
ZLSP-D 230C | 11 kW | 120-200 | 290/320 | 1200x560x950 | ||
ZLSP-D 260C | 15 kW | 160-250 | 340/370 | 1240x560x1000 | ||
ZLSP-D 300C | 22 kW | 250-400 | 425/465 | 1300X620X1100 | ||
| Diesel engine | ZLSP-D 150A | 8HP | 50-100 | 180/220 | 100x500x750 |
ZLSP-D 200A | 15 HP | 80-120 | 210/240 | 1460x750x900 | ||
ZLSP-D 230A | 22 HP | 120-200 | 280/310 | 1560x850x1100 | ||
ZLSP-D 260A | 30 HP | 160-250 | 330/360 | 1200x500x1070 | ||
ZLSP-D 300A | 41 HP | 250-400 | 410-450 | 1220x600x1000 | ||
| Gasoline engine | ZLSP-150Q
| 7.5HP | 90-120 | 180-220 | 1000x500x750 |
| PTO | ZLSP-D 150P | ≥8 HP | 50-100 | 90-110 | 900x540x1020 |
ZLSP-D 200P | ≥15 HP | 80-120 | 130/150 | 1000x540x1020 | ||
ZLSP-D 230P | ≥22 HP | 120-200 | 175/200 | 1000x540x1020 | ||
ZLSP-D 260P | ≥33 HP | 160-250 | 235/255 | 1050x540x900 | ||
ZLSP-D 300P | ≥41 HP | 250-400 | 305/325 | 1100x540x1000 |
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
About the machine:
Q1. Does this machine can make wood pellets?
Answer: This machine can make both wood pellets and feed pellets. When making feed pellets, it performs better and the capacity is bigger.
Q2. What are the spare parts for this series pellet machine?
Answer: The spare parts for this machine are one die and two rollers.
Q3. How often should I change the spare parts?
Answer: The long life time of the die and rollers is 1500 hours at least. It needs to change the easy wear parts every five months. If maintained and used well, the parts can be used about EIGHT months or more.
