TWLL Series Pellet Hopper Micro Screw Feeder

Specifications

Screw feeder
1.One year warranty
2.ISO9001:2000,CE,GOST,SGS
3.High output with CPM advanced technology
4.Reliable supplie

TWLL series Screw Feeder

1. One year warranty
2. CE certificated
3. High efficiency
4. Chain/belt conveyor1. CE and GOST certificated
5. Easy installation



Application Scope and Features

1. TWLL,TWLLy series screw feeder is the fixed conveying equipment. It is widely used for the horizontal conveying of the pellet or powder materials like grain, oil etc. as well as slanting conveying (angle≤20°).

2. TWLL, TWLLy series screw feeder is not fit for the conveying of corrosive, lumpy, glutinous , rough materials like corn, rice ,etc. It can not work under -20°C or above 50°C.

3. This conveyor adopts chain drive. Direct drive can also be adopted. Frequency converting motor can be adopted. It has the features of simple structure, good stableness, good sealing , easy maintenance, accurate feeding, etc.



Main Technical parameters



Model	Screw Dia. (mm)	Inner Machine Dia. (mm)	Gap between blade and inner wall (mm)	Max. Speed Recommended (rpm)	Capacity(t/h)
TWLL12	φ120	φ130	5	135	2~10
TWLL16	φ160	φ170	5	135	6~15
TWLL20	φ200	φ210	5	135	10~25
TWLL25	φ250	φ260	5	130	12~40
TWLL32	φ320	φ332	6	115	20~50
TWLL40	φ400	φ414	7	100	40~80



Model	Screw Dia. (mm)	Inner Machine Dia. (mm)	Gap between blade and inner wall (mm)	Max. Speed Recommended (rpm)	Capacity(t/h)
TWLLy12	120	128	4	135	2~8
TWLLy16	160	170	4	135	6~12
TWLLy20	200	210	5	135	10~20
TWLLy25	250	260	5	130	12~32
TWLLy32	320	230	5	115	16~40





We are specialized in designing and manufacturing poultry feed,aquatic feed pellet machinery,biomass pellet machinery and the complete production line(all auxiliary equipment) with CPM advanced technology.







Widely used in chemical, cement, pharmacy, iron   &   steel , food industry and so on.

-  Customized desighed and installation

-  Carbon steel ,stainless steel 304/316







Company introduce

    Liyang City Rongda feed Equipment Co., Ltd., was established in January 2005, is located in the superiorinvestment environment in Tai Tau Industrial Area,covering over 25,000 m2, building area of more than 13,000 square meters, office building covers an area of?more than 500 square meters.
   The Rongda company is the one for many yearsspecialized in biomass.....





Why buy from us?
1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2.Delivery fast -----Goods be sent out within 15 to30 days based on order quantity.
3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
