Specifications
rubber conveyor belt1.transport capacity25-980m3/h
2.motor power1.5-22
3.simple structure
4.ISO certificate
Easy install rubber conveyor belt
Introduction of belt conveyor:
Belt Conveyor is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force. The Belt Conveyor is advanced and simple in structure, easy to maintain. Its transfer capacity is high, transfer distance is long. They are widely used in mining, metallurgical and coal industry to transfer sandy or lump material, or packaged material. In many situation, it Is a very important component of nonstandard machinery.
Features of belt conveyor:
It mainly consists of frame rack, belt, roller, transmission part. The frame rack is made of steel; the belt is made of cotton or nylon as the core. It has the advantages of big conveying capacity, simple structure, convenient repair and standard parts.
Application of belt conveyor:
YuHui conveyor is adaptable to both stationary and mobile crushing plants, it is widely used in mining, metallurgical and coal industry to transfer sandy or lump materials, or packaged materials. The transfer system can be one single or multi-conveyors or combined with other transfer equipments according to various transferring requirements. And YuHui belt conveyor can be installed horizontally or aslope to meet the needs of different transfer lines.
Working principle of belt conveyor:
The motor drives the driving rollers of the belt conveyor, and drives the roller by the strong belt advances. Materials are conveyed from the original place to the place where they are needed.
Main technical parameters of rubber conveyor belt:
Type |
Capacity(m3/h) |
Diameter(mm) |
Motor power (kw) |
B500 |
25-143 |
500 |
1.5-3 |
B650 |
40-243 |
630 |
1.5-4.5 |
B750 |
75-500 |
630 |
2.2-7.5 |
B1000 |
140-770 |
800 |
4-11 |
B1200 |
200-980 |
1000 |
5-22 |
