grinding mill for construction industry
1. grinding mill
grinding mill produced by our company is mainly used to grind non-inflammable and non-explosive materials with Mohs hardness below 7 and moisture content below 6% such as barite, calcite, potash feldspar, talcum, marble, limestone, ceramic, glass, etc Raymond grinder can be used in mining, chemical industry, construction materials, metallurgy and so on. The final products can be adjusted freely from 100 mesh to 425 mesh.
2. grinding mill
Working Principle of grinding mill
Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.
3. grinding mill
Technical Parameter of grinding mill
Model |
Roller Number |
Roller Size |
Maximum Feed Sizemm) |
Fineness of final productmm) |
Outputt/h |
Main Frame power (kW) |
Fan power (kw) |
Overall Dimension(mm)
|
5R4119 |
5 |
410×190 |
20-25 |
0.613-0.044 |
5-12 |
75 |
55 |
7850×8000×9700 |
4R3216 |
4 |
320×160 |
20-25 |
0.28-0.047 |
1.0-8.0 |
37 |
30 |
9900×5800×10580 |
4R2715 |
4 |
270×150 |
15-25 |
0.28-0.047 |
0.8-4.0 |
22 |
18.5 |
8700×5000×7819 |
3R2715 |
3 |
270×150 |
15-20 |
0.28-0.047 |
0.7-3 |
22 |
18.5 |
8700×5000×7819 |
3R2615 |
3 |
260×150 |
15-20 |
0.28-0.047 |
0.5-2.7 |
18.5 |
15 |
5650×3305×5950 |
3R2115 |
3 |
210×150 |
15-20 |
0.28-0.047 |
0.4-1.6 |
15 |
11 |
4500×2800×5800 |
3R1410 |
3 |
140×100 |
5-10 |
0.28-0.047 |
0.1-1.0 |
7.5 |
5 |
3200×2100×4500 |
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
YuHui Mining machinery Co., Ltd. owns 20-year experience. Products are sold home and abroad. Our fine service has been accepted by our foreign customers. Welcome new and old customers to visit and negotiate.
